IC620EDR028 Technical Specifications

Manual GFK-0803B
MPN IC620EDR028
Product Type Expander Unit
Voltage 265 VAC

Product Description

The IC620EDR028 device is an expander unit that GE Fanuc made for the Micro PLC series. Typically, AX Control will have this product, along with many other products in the Micro PLC series, so be sure to check whether or not this product is currently in our stock by going on our website or talking over the phone with one of our staff members.

The IC620EDR028 expander unit will provide the operator with 28 additional points, with 16 DC inputs and 12 relay outputs. The power supply voltage rating for this unit is set anywhere from 85 VAC to 264 VAC at a range of 47 to 63 Hz. The rating for this device’s power consumption is 8.1 VA while the power available from the VPP terminal is unfused 8.4 mA per unused input at 24 VDC. Also, both this device’s voltage drops and its interruptions are rated as being 50 ms at 85 VAC of power input.

The IC620EDR028 expander unit has 16 DC inputs, all of which are opto-isolated from the logic circuitry. For these inputs, the rated voltage is open circuit and is set to 24 VDC +/- 3.6 VDC. The input current is set to 8.4 mA and the input impedance is set to 3 kΩ.

The IC620EDR028 expander unit also has 12 relay outputs, all of which are electromechanical relay contact type. These relay outputs have normally open contacts. The contact resistance for these outputs are rated at a maximum of 30 mΩ and the minimum load is 5 VDC at 1 mA.

Frequently Asked Questions about IC620EDR028

What is the purpose of the IC620EDR028?
The IC620EDR028 is a expander unit that provides additional input/output points to a CPU. The IC620EDR028 attaches onto the side of the CPU via a expander unit ribbon cable.
Does the IC620EDR028 come equipped with a connector cable?
The IC620EDR028 comes equipped with the expander unit ribbon cable that allows for the unit to attach onto the CPU.
How many input/output points does the IC620EDR028 have?
The IC620EDR028 was designed with 28 input/output points. There are 16 DC input points and 12 relay outputs that are all located on the outside of the device.
Will AX Control troubleshoot my IC620EDR028?
AX Control technicians are able to troubleshoot your device and figure out the issues that are causing it to preform poorly. Once the issue is found, AX Control can complete any repairs needed to get it fully functioning.
