IC620EDR014 Technical Specifications

Manual GFK-0803B
MPN IC620EDR014
Product Type Expander Unit
Voltage 265 VAC

Product Description

The IC620EDR014 module is an expander unit for the Micro PLC series that was made by GE Fanuc. If you are searching for this product, look no further than AX Control, since we usually have this product in stock. To verify the availability of this product, you can either give us a call during our business hours or check here on our website.

The IC620EDR014 expander unit provides a total of fourteen extra I/O slots, with eight DC inputs and six relay outputs. As a whole, the IC620EDR014 expander unit’s power supply voltage has a range of 85 VAC to 264 VAC at 47 to 63 Hz and a power consumption rating of 8.1 VA. The power that is available from the VPP terminal is unfused 24 VDC, 75 mA with 8.4 mA per unused input. The IC620EDR014 expander unit’s voltage drop and interruptions rating is 50 ms at 85 VAC power input.

The IC620EDR014 expander unit’s eight inputs have an input current of 8.4 mA and an input impedance of 3 kΩ. When turned ON, the level for the IC620EDR014 expander unit’s inputs is at a maximum of 10.8 VDC. When turned OFF, the level for the inputs is at a minimum of 11.0 VDC.

The IC620EDR014 expander unit’s outputs are electromechanical relay contact type with normally open contacts. There are three points for each individual common. The IC620EDR014 expander unit’s outputs have a minimum applicable load of 5 VDC at 1 mA. The relay life for these outputs is 20 million mechanical operations.

Frequently Asked Questions about IC620EDR014

How many I/O points does the IC620EDR014 have?
The IC620EDR014 is equipped with 14 I/O points located on the outside of the device. The IC620EDR014 is designed to have 8 DC inputs as well as 6 relay outputs.
How does the IC620EDR014 attach to the CPU?
The IC620EDR014 is designed to connect to the side of a CPU in the GE Fanuc Micro Series. The IC620EDR014 requires a expander unit ribbon cable to connect the two devices.
What are the dimensions of the IC620EDR014?
 The dimensions of the IC620EDR014 are 5.5W x 3.15H x 3.0D inches.
