IC300ADC020

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
2 Point Analog Current 4-20MA

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a IC300ADC020 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IC300ADC020
  • SKU: IC300ADC020GFP
  • Manufacturer: GE Fanuc PLC
  • Series: IC300 OCS

IC300ADC020 Technical Specifications

Manufacturer GE Fanuc
Series Smart Stack
MPN IC300ADC020
Type Analog Input Module

About the IC300ADC020

The IC300ADC020 unit is an analog input module which was developed by GE Fanuc for their series of various modules that is called SmartStack. This module can usually be seen in our inventory. You can check on its definitive status in our stock at any time by looking on our website or by talking directly with one of our staff members during our business hours.

The IC300ADC020 analog input module has a total of two channels that have a nominal input range of 0 through 20.47 mA. The input impedance is different based on the status of the IC300ADC020 analog input module. It can be 100 Ohm < 12 VDC, clamped at 12 VDC, and 35 mA maximum continuous. In addition to that, the input current is 0 through 20 mA. The required power at steady state is 0.09 W, with 4.1 mA at 24 VDC, and a maximum overcurrent of 35 mA. There is no external power supply that is designed for the IC300ADC020 analog input module.

The IC300ADC020 analog input module uses the successive approximation convertor type. The conversion time is set by the PLC scan time. The accuracy of this module versus the temperature is .005% / degrees Celsius. The internal power budget is 35 mA. Lastly, this device uses removable spring clamp type terminals.

When installing, be sure to abide by the applicable standards and codes and to use shielded, twisted-pair wiring for optimal performance.

The IC300ADC020 analog input module has a total weight of 0.56 lbs. or 0.26 kg.

Frequently Asked Questions about IC300ADC020

What is the function of the IC300ADC020?
The IC300ADC020 is a analog input module that is designed with 3 input channels. The IC300ADC020 is a device in conjunction with the Smart Stack Series.
What is the resolution on the IC300ADC020?
The resolution on the IC300ADC020 is 12-bit.
Which applications is the IC300ADC020 compatible with?
The IC300ADC020 is compatible with small industrial machines, packaging equitment, and conveying systems.
