Product Description

The 6KP1123005X1B1 is a 5HP 230V AC Drive in the GE Fuji AF-300 G11 series of drives. This drive is a legacy model and is no longer receiving support from GE. It may be difficult to find, but AX Control does try to keep it stocked.

The 6KP1123005X1B1 is 3-Phase, 50/60 HZ, and 230 VAC. It is 8.4 lbs. and is 10.24” tall, 5.91” wide, and 5.71” deep. It has an overload of 19 amps that can be 110% for 1 minute. It has a rated output current of 17 amps. It has an output power rating of 6.7 KVA. When ranked at 15KHz, it has a wattage loss of 210W and when ranked at 2KHZ it has a 170W power loss. This drive is not meant for single-phase usage or other types of motors beyond 3-phase induction motors.

The 6KP1123005X1B1 is protected by a NEMA 1 type enclosure. It is vented and should only be used in indoor locations. Keep this drive away from corrosive or combustible materials. The salt content in the atmosphere around this drive should also be minimized. It is a small rectangular device that has several basic features on its surface cover. It has a keypad panel, a surface and intermediate covering, a ratings nameplate, and four small mounting brackets at the corners of the backside of the drive. This drive should be mounted to a flat metallic surface and should remain vertical. It should never be to operate on the floor or be horizontally mounted to a surface.

Frequently Asked Questions about 6KP1123005X1B1

Who makes the 6KP1123005X1B1?

Fuji Electric is the manufacture of the 6KP1123005X1B1

What series is the 6KP1123005X1B1 in?

The 6KP1123005X1B1 can be found in the AF-300 P11 series.

What is the horsepower rating for the 6KP1123005X1B1?

The horsepower rating for the 6KP1123005X1B1 is 5hp.

How much does the 6KP1123005X1B1 weigh?

The 6KP1123005X1B1 weighs 8 pounds.

Does the 6KP1123005X1B1 have any NEMA enclosures?

The 6KP1123005X1B1 has one (1) NEMA enclosure.

What are the dimensions for the 6KP1123005X1B1?

The dimensions for the 6KP1123005X1B1 are 10.24 (H) x 5.91 (W) x 5.71 (D) in inches.

Should the 6KP1123005X1B1 be installed a certain way?



The 6KP1123005X1B1 should installed in a fireproof material such as metal. The drive can get quite hot while running. To keep the temperature of the drive low allow for adequate ventilation to cool the drive.

How many phases does the 6KP1123005X1B1 have?

The 6KP1123005X1B1 is a 3 phase drive.

Does the 6KP1123005X1B1 need to be grounded?

Yes, the 6KP1123005X1B1 must be grounded. The connector used to ground the drive should be sized in accordance with the Canadian Electrical Code or the NEC (depending on where your facility is located). The connection to the grounding terminal should be made using a UL listed or CSA certified closed loop connector. This connector must be the correct size for the gauged wire that is being used.

Are there any hazard with the 6KP1123005X1B1?

Yes, the 6KP1123005X1B1 has the potential hazard for burns or electrical shocks if handled improperly. Only trained personnel should handle, install, or repair this device.
