2hp AF-60LP Micro Drive with Process PI Controller

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 6KMS243002N1A1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 6KMS243002N1A1
  • SKU: 6KMS243002N1A1GD
  • Manufacturer: GE Drives
  • Series: Fuji Electric

About the 6KMS243002N1A1

The AF-60LP Micro Drive is part of the General Electric’s AF-60 Drive family. The IP20 structure of this drive is open, but a NEMA 1 kit is available for sale and is attachable to the drive. Since this is a micro drive, the power of this device concentrates into a smaller space. The dimensions of this device are 7.09 x 2.95 x 6.85 and it weighs 3.53 pounds. The AF-60LP Micro Drive also has a mounting kit that also is for sale. Purchasing this attachment could help organize the work space that this drive resides. This drive comes with many features to improve the experience of the drive. The keypad interface comes with a tuner that could be used to adjust settings. The device comes with two controllers, a process PI controller and a logic controller. The drive also comes with an auto tuner that tunes values with limited user interaction. The micro drive also comes with other built-in features. Some of the features are; a RFI filter, a Brake chopper, and a single-turn potentiometer.

The AF-60LP Micro Drive runs at 2 horsepower, and has an output power of 1.5 kilowatts. The output rating of the device is 3.7 amps. The general efficiency rating of the micro drive 97.2% with a wattage loss of 56.5.

The AF-60LP Micro Drive uses three separate input phases to work together and complete the operations of the drive. The input voltage of the device is 460V, 50/60 Hz.

Repair Services For 6KMS243002N1A1

Type Lead Time Price Action
Repair Service 1-2 weeks $951

Our highly skilled technicians can repair your 6KMS243002N1A1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

6KMS243002N1A1 Manuals, White Papers, Data Sheets, and Troubleshooting
