GE AF-60 LP 5HP 3 Phase 230VAC Micro Drive by GE



Sell Surplus: Have a 6KLP23005X9A1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 6KLP23005X9A1
  • SKU: 6KLP23005X9A1GD
  • Manufacturer: GE Drives
  • Series: AF-60 LP Drives

6KLP23005X9A1 Technical Specifications

Manufacturer General Electric
Series AF-60
Part Number 6KLP23005X9A1
Input Voltage 380-480 VAC
Enclosure IP20
Phase 3 Phase
Hz 50/60Hz

Product Description

6KLP23005X9A1 is an AF-60LP Micro Drive that is manufactured by GE. This particular 3-phase drive has an input voltage of 208/230 volts. The horsepower rating is 5 HP. The drive has a number of protections and features that prevent issues and failures. These include electronic thermal motor protection, temperature monitoring of the heatsink, shorts circuit protection for the frequency converter, alarms if a motor or mains phase is missing, monitoring of the intermediate, and earth fault protection for the frequency converter.

The following information applies to the mains supply: The supply frequency is 50/60 Hz. The maximum imbalance temporary between mains phases is 3.0% of the rated supply voltage. The true power factor is greater than or equal to 0.4 nominal at the rated load. The displacement power factor near unity is greater than 0.98. The following information applies to the motor output on terminals U, V, and WL The output voltage is 0-100% of the supply voltage. The output frequency is 0-200 Hz (VVC+), 0-400 Hz (u/f). Switching on the output is unlimited. The ramp times are 0.05 - 3600 seconds. There are two analog inputs on the drive at terminals 53 and 60. The voltage level on these inputs is 0-10 V. The input resistance is approximately 10 kΩ. There are also 5 programmable digital inputs on terminals 18, 19, 27, 29, and 33. The voltage level is 0-24 VDC. The maximum voltage on input is 28 VDC. The input resistance is approximately 4 K.

Frequently Asked Questions about 6KLP23005X9A1

What are the output amps on 6KLP23005X9A1?
6KLP23005X9A1 has a minimum of 3.4 output amps. 6KLP23005X9A1 has a maximum of 3.7 output amps.
What does the green LED indicator mean on 6KLP23005X9A1?
The green LED on 6KLP23005X9A1 means that the 6KLP23005X9A1 frequency converter is on.
What types of parameters does 6KLP23005X9A1 have?
6KLP23005X9A1 has standard data type parameter values. 6KLP23005X9A1 also has non standard type. For descriptions of the parameter values, view the manual - manual DET579A.

Repair Services For 6KLP23005X9A1

Type Lead Time Price Action
Repair Service 1-2 weeks $303

Our highly skilled technicians can repair your 6KLP23005X9A1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
