About the IS215SECAH1A
IS215SECAH1A Device Hardware Details
While not a huge selection of original factory-issued manual information surrounding the IS215SECAH1A printed circuit board is available online, a helpful crop of material asserting its status as a Solar MACC-BPPB-WEMD Assembly is a strong starting place. Other information concerning the series and individual-product status of the IS215SECAH1A board is available upon a diligent visual inspection, paired with a supplementary individualized IS215SECAH1A product number breakdown.
For starters, two of the more obvious hardware components integrated into the base board of the IS215SECAH1A PCB can be identified in standard-issue ethernet ports, which are positioned across from each other lengthwise on the large printed circuit board. While the IS215SECAH1A board itself contains no other ethernet ports, its attached BPPB daughteboard centrally features two exactly similar ethernet ports.
Eight other ports are available to the drive administrator, attached to this IS215SECAH1A board. These ports are all female ports, factory-mounted through the use of screw standoffs to the edge of the IS215SECAH1A board for connection efficiency.
IS215SECAH1A Product Number Analyzed
Moving past the various female ports made available to the IS215SECAH1A board user, a series of integrated circuits are incorporated into this SECA module's design. Each of these should be marked with individual reference designators, and some of them appear to sport their own factory-applied reference stickers with individual component specifications. A final highlightable hardware trait obvious to the board assembly of the IS215SECAH1A is its series of factory-drilled holes. Included for installation purposes, these factory-drilled holes are all insulated for complete surface and interior voltage protection, and they exist in a set of five in total on the IS215SECAH1A board.
While a litany of pertinent information about the IS215SECAH1A printed circuit board is evident upon a simple visual inspection alone, more facts about this product are retrievable from a simple breakdown of the unique IS215SECAH1A part number, including its:
- special assembly version
- SECA functional acronym
- chemically-applied conformal PCB coating protective coating style
For a more thorough, diagrammed explanation of this IS215SECAH1A part number, please refer to the IS215SECAH1A Part Number Breakdown attached above in the manuals tab.
