Mark V General Electric TCQE Card DS215TCQEG1AZZ01A is a Q Core Processor that will have fifteen core couple thermocouple inputs for protection and monitoring. This unit will have fifteen thermocouple inputs for each redundant application, for a simplex application, there are fifteen and 45 for TMR applications.



Sell Surplus: Have a DS215TCQEG1AZZ01A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215TCQEG1AZZ01A
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS215TCQEG1AZZ01A Technical Specifications

Core Type Q Core
Manufacturer GE General Electric
Thermocouple Input for Simplex Mode 15
Series Mark V
Part Number DS215TCQEG1AZZ01A
Product Type Circuit Board and Firmware
Instruction Manual GEH-6195

Product Description

Model DS215TCQEG1AZZ01A is part of the Mark V System from General Electric and is a TCQE/Circuit and Firmware Card. This card will have a Q core component that will help with protection and monitoring. In each redundancy mode, there will be fifteen thermocouple inputs, for a simplex redundant application there will only be fifteen inputs, whereas in triple modular redundant applications there will be forty-five inputs. One vital note to take into consideration when operating this model is that the Q core is an optional feature when being used in a Gas Heavy Duty prom set.

When the DS215TCQEG1AZZ01A card is being operated it can be used with gas or steam turbine prime mover applications. Features that are probable when used in these two prime mover applications are as follows:

  • Online Maintenance

  • Built-In Diagnostics

  • Common Hardware Platform for Steam and Gas Applications

  • Software-Implemented Fault Tolerance

All of these features are primary features when this model is used in the Mark V System of devices. Some of the diagnostic features are power-up and background-initiated routines.

The DS215TCQEG1AZZ01A model is obsolete now that it is no longer being produced by General Electric, as such, it is very difficult to find. If you have a model that is in need of repair AX Control’s team of specialists has the ability to repair this device for you. For more information regarding the repair pricing of this model please contact AX Control at (919) 372-8413 or sales@axcontrol.com

Frequently Asked Questions about DS215TCQEG1AZZ01A

What are DS215TCQEG1AZZ01A's inputs reserved for?
DS215TCQEG1AZZ01A's inputs are reserved for the T2 and T25 RTD's in the LM6000 application because DS215TCQEG1AZZ01A's inputs are the only ones that can be configured as 200 ohm RTD's.
Which core is DS215TCQEG1AZZ01A found in?
DS215TCQEG1AZZ01A is used in a < Q > core, but the < Q > core DS215TCQEG1AZZ01A can be found in is an optional feature for Gas Heavy Duty prom set only, using the TCQF cards.
