The General Electric DS215TCQBG1BZZ01A Circuit Board with Firmware was made for the Mark V Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS215TCQBG1BZZ01A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215TCQBG1BZZ01A
  • SKU: DS215TCQBG1BZZ01AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS215TCQBG1BZZ01A Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS215TCQBG1BZZ01A
Product Type Circuit Board and Firmware
Instruction Manual GEH-6195
Revision Quantity 1 Revision
Assembly Type DS215 Special Assembly

About the DS215TCQBG1BZZ01A

The DS215TCQBG1BZZ01A is a GE Circuit Board for a Mark V series system. This board is now part of a legacy series and may be somewhat difficult to find. AX Control does try to keep this board in stock as a new surplus or refurbished stock part. Please contact us directly for more information about its availability, pricing, and shipping options. While a legacy series, the Mark V Turbine Control System Series that this DS215TCQBG1BZZ01A product offering belongs to is additionally definable as one of the final General Electric product series to make use of their patented Speedtronic control system technology. While this DS215TCQBG1BZZ01A PCB is definable as a Circuit Board with Firmware in its own functional right, this DS215TCQBG1BZZ01A product is an edited version of the original DS215TCQBG1BZZ01 Circuit Board with Firmware; possessing a singular A-rated functional product revision.

Hardware Tips and Specifications

The DS215TCQBG1BZZ01A is a large rectangular printed circuit board (PCB) that has factory drilled holes on each of the four corners and one in the center of each of the board’s edges. These holes can be used to help mount the board. This board can be mounted into a card rack within a Mark V hardware cabinet. This board does come with firmware. There are many different components on the DS215TCQBG1BZZ01A. On the bottom edge of the board are four different male pin connection ports. On the bottom left side of the board are nine integrated circuits that are surrounded by small yellow capacitors. Above the nine integrated circuits are nine resistors, six red jumpers, and nine red resistor networks. Above the resistor networks is another set of integrated circuits, and capacitors. There are seven more resistors and nine resistor networks. Above that are 14 more integrated circuits surrounded by yellow capacitors. On the top edge of the board next to the integrated circuits are two EPROMs next to and above four relays. Under the relays are 12 more integrated circuits with diodes surrounding them, two more EPROMS, eighteen more yellow resistor networks, and an additional two FPGAs.

The above information represents about the extent of original DS215TCQBG1BZZ01A board information available after a thorough guided visual inspection of the product itself. This was necessary given the DS215TCQBG1BZZ01A Circuit Board's status as a member of a General Electric legacy series, which buries many of its originally-available instructional manual materials. With this in mind, the DS215TCQBG1BZZ01A functional product number itself is considered a strong source of DS215TCQBG1BZZ01A product-specific hardware information, beginning with the DS215 series tag holding dual naming responsibilities for the DS215TCQBG1BZZ01A product. This DS215 series tag identifies the DS215TCQBG1BZZ01A Circuit Board with Firmware here as a domestically-manufactured General Electric product with a special DS215 modular assembly. Some of the other important DS215TCQBG1BZZ01A board hardware details revealed in its DS215TCQBG1BZZ01A functional product number include this DS215TCQBG1BZZ01A PCB's:

  • TCQB functional product acronym
  • Normal style of PCB protective coating
  • Group one Mark V Series product grouping
  • Possession of an option firmware package
  • A-rated functional product revision

Frequently Asked Questions about DS215TCQBG1BZZ01A

How does DS215TCQBG1BZZ01A help a Mark V excite accelerometer vibration sensors and scaling accelerometer feedback signals?
The first three proximity transducer/accelerometer input points to the DS215TCQBG1BZZ01A can be used as accelerometer inputs, which involes setting I/O configuration constants and positioning hardware jumpers on DS215TCQBG1BZZ01A to accept accelerometer inputs rather than proximity transudcer inputs. When defining one or more of the first three vibration inputs to DS215TCQBG1BZZ01A as an accelerometer input, the value must be entered into the appropriate fields on the DS215TCQBG1BZZ01A vibration proximity transducer shaft location assignment screen.
Which control processors can DS215TCQBG1BZZ01A fit into?
DS215TCQBG1BZZ01A is used in Mark V controllers < R >, < S >, < T > for TMR or < R > for simplex.
What are DS215TCQBG1BZZ01A's screens used for?
Several DS215TCQBG1BZZ01A I/O configurator screens are used to configure proximity transducer inputs for a Mark V controller.
What is jumper J1 on DS215TCQBG1BZZ01A?
DS215TCQBG1BZZ01A's J1 jumper is the 20/200 mA Output Circuit #1 Mode Select jumper on DS215TCQBG1BZZ01A. This jumper on DS215TCQBG1BZZ01A is default set to Simplex.
Which manual is helpful with DS215TCQBG1BZZ01A?
The manual found most helpful with DS215TCQBG1BZZ01A is the Speedtronic Mark V Turbine Control Application Manual, Manual GEH-6195. This manual covers a variety of information on Mark V controllers and Mark V applications but the manual also adresses each card for a Mark V controller and the manual addresses DS215TCQBG1BZZ01A specifically.

Reviews For DS215TCQBG1BZZ01A

Internal Review
(5.0)

This DS215TCQBG1BZZ01A printed circuit board from General Electric's Mark V Turbine Control System Series is solely-definable through its simple functional description as a Circuit Board with Firmware. With this being the case, this DS215TCQBG1BZZ01A PCB is a well-supported Speedtronic product, with an A-rated functional revision and a special assembly. This DS215TCQBG1BZZ01A PCB is available today for repair or replacement. - AX Control Lead Technician

Repair Services For DS215TCQBG1BZZ01A

Type Lead Time Price Action
Repair Service 1-2 weeks $635

Our highly skilled technicians can repair your DS215TCQBG1BZZ01A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
