The DS215TCEAG1BZZ01A Emergency Overspeed Board was manufactured by General Electric, for the Mark V Series of turbine control systems.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DS215TCEAG1BZZ01A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215TCEAG1BZZ01A
  • SKU: DS215TCEAG1BZZ01AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS215TCEAG1BZZ01A Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS200TCEAG1BZZ01A
Functional Description Emergency Over Speed Board
Functional Acronym TCEA
PCB Coating Normal Coating
Functional Revision 1 B
Functional Revision 2 Z
Artwork Revision Z

About the DS215TCEAG1BZZ01A

The General Electric Emergency Overspeed Board with EPROM modules DS215TCEAG1BZZ01A features one microprocessor and multiple erasable programmable read only memory (EPROM) modules. It also contains 3 fuses, 30 jumpers, and a pair of bayonet connectors. The GE Emergency Overspeed Board with EPROM modules DS215TCEAG1BZZ01A comes with EPROM modules installed on the board. The EPROM modules have the firmware and programming instructions stored on them that the microprocessor uses for normal processing. Installation of this board might be appropriate if the original board contains EPROM modules that are damaged. Before you install the board there are some considerations to keep in mind concerning handling the EPROMs. Wear a wrist strap when you handle the board to prevent static build up. Static can damage the information stored on the EPROM which would prevent the microprocessor from functioning.

The wrist strap utilized for normative installation of this DS215TCEAG1BZZ01A Emergency Overspeed Board provides a means for the static to exit your person or the board by giving a grounded metal surface that the static electricity seeks out. One end of the strap is connected to your arm or wrist and the other end is a clip device that attaches to a metal chair or desk support. Some straps contain a plug that attaches to a connector on a metal surface or a work table. Either way, the static on your person and the board are kept from building up and damaging the EPROM.

Several crucial connecting hardware elements have been included or considered compatible with this DS215TCEAG1BZZ01A Emergency Overspeed Board including but not limited to:

  • The J7 Power Distribution Connector
  • The JK TCEB Board Signal Carrier Connector
  • The JL Trip Signal-Focused Connector
  • The JW Flame Detector 335 V dc voltage Connector
  • JX1 Daisy Chained IONET Connectors
  • JX2 Daisy Chained IONET Connectors

The various hardware elements and connections made on the outward interface of this DS215TCEAG1BZZ01A Emergency Overspeed Board should recieve at least a solid basis of protection from the normal style of PCB coating that has been afforded to this General Electric product.

Frequently Asked Questions about DS215TCEAG1BZZ01A

What is DS200TCEAG1BZZ01A a part of?
DS200TCEAG1BZZ01A is a part of the < P > core or protective interface module.
How is DS200TCEAG1BZZ01A programmed?
There are a series of berg jumpers that program DS200TCEAG1BZZ01A to the location in the < P > core where DS200TCEAG1BZZ01A res
What is DS200TCEAG1BZZ01A responsible for?
DS200TCEAG1BZZ01A is responsible for processing the overspeed and flame detection trip signals.
