This DS215KLDBG1AZZ02A Key/LED/Display Board was first mass-produced for General Electric's Mark V Series.



Sell Surplus: Have a DS215KLDBG1AZZ02A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215KLDBG1AZZ02A
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS215KLDBG1AZZ02A Technical Specifications

Manufacturer General Electric
Series Mark V Speedtronic
Product Number DS215KLDBG1AZZ02A
Functional Acronym KLDB
PCB Coating Style Normal Coating
Assembly Type DS215 Special Assembly
Optional Firmware AZZ02 Firmware Applied

Product Description

The DS215KLDBG1AZZ02A module is a General Electric printed circuit board designed to integrate with the company’s Mark V turbine control system. The Mark V Speedtronic turbine control system was one of GE’s later turbine control systems and offered microprocessor-based modular units that could easily be serviced and/or replaced. While GE no longer manufactures or supports DS215 level boards, our company works hard to maintain on-hand stock of these components. Let our team know if you would like to be quoted on reconditioned or surplus never-used stock, or both. We often have both options available within our stock. This DS215KLDBG1AZZ02A module is considered a PCB with both a special assembly version and available optional firmware. In addition to this, this DS215KLDBG1AZZ02A printed circuit board is classified as possessing a singular, A-rated functional product revision.

Hardware Tips and Specifications

The DS215KLDBG1AZZ02A functions as a Display Keypad Card, and, typically with any Mark V Series product offered here at AX Control, is comprised of its own specific set of hardware component inclusions and specifications. It is built with two vertical pin cable connectors located along its top edge. Many resistor network arrays are placed along the top half of the board, interspersed with resistors, capacitors, and diodes.  Additionally, there are integrated circuits, FPGAs, and oscillating chips in this area, along with many of the board’s 32 individual lights. This DS215KLDBG1AZZ02A board additionally has space for seven LED panels, each of which has sixteen alphanumeric digits.

The previous information represents about the totality of information concerning this DS215KLDBG1AZZ02A Key/LED/Display Board available in original General Electric instructional manual materials. With this being said, the DS215KLDBG1AZZ02A alphanumeric product number alone is a great purveyor of series-specific identifactory information, starting with its DS215 series tag. This DS215 series tag in the DS215KLDBG1AZZ02A functional product number has dual naming responsibilities for this product, detailing it both as a Mark V Series PCB with a special assembly version and as a GE product manufactured domestically. Some of the other information retrievable from this individualized product number includes the DS215KLDBG1AZZ02A Key/LED/Display Board's KLDB functional acronym, its normal style of PCB coating, its optional firmware package, and its single A-rated functional product revision.

Frequently Asked Questions about DS215KLDBG1AZZ02A

What does this DS215KLDBG1AZZ02A Key LED Display Board's Ds215 special assembly refer to?

While the true meaning of this DS215KLDBG1AZZ02A PCB's DS215 special assembly is not known for certain, it can be theorized to be a representation of this device's acceptance of multiple Mark V Series LED panels in its assembly.

Does this DS215KLDBG1AZZ02A Key LED Display Board have any drilled installation holes?

Yes. As with the majority of Mark V Series products available here through AX Control, this DS215KLDBG1AZZ02A Key LED Display Board has a series of insulated drilled holes for installation purposes.

Reviews For DS215KLDBG1AZZ02A

Internal Review

This DS215KLDBG1AZZ02A Key LED Display Board from General Electric's Mark V Series of turbine control systems is a tantalizing option for your automated industrial needs, especially considering some of this device's robust hardware and software inclusions. The lengthy AZZ02A tag at the very end of this product's DS215KLDBG1AZZ02A alphanumeric part number is reminiscent of the software package introduced to this Mark V Series product, which itself should be supported in function by the DS215 special assembly version afforded to this model of PCB. - AX Control Lead Technician
