The DS215DMCAG2AZZ02A DOS Main Control Board was manufactured by General Electric for the Mark V Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS215DMCAG2AZZ02A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215DMCAG2AZZ02A
  • SKU: DS215DMCAG2AZZ02AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS215DMCAG2AZZ02A Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS215DMCAG2AZZ02A
Functional Description DOS Main Control Board
Functional Acronym DMCA
PCB Coating Normal Coating
Assembly Type DS215 Special Assembly

About the DS215DMCAG2AZZ02A

The DS215DMCAG2AZZ02A is a circuit board component that was manufactured by General Electric to be used as part of their Mark V gas/steam turbine management system. The MKV was part of GE’s Speedtronic line, which began in the late 1960s and continued its development throughout the century.  While MKV circuit boards are no longer available as OEM parts, they can be purchased from AX Control as fully tested and refurbished units. As indicated in the above-attached Mark V Series extended series name, this DS215DMCAG2AZZ02A product offering's greater Mark V Series has specific applications in the control and management systems of compatible and popular wind, gas, or steam turbine automated drive assemblies. While a now-obsolete legacy product series, the Mark V Turbine Control System Series that this DS215DMCAG2AZZ02A modular assembly offering belongs to is still highly-sought within the automated industrial marketplace; primarily an indication of its attached Speedtronic control system technology as explained above. This DS215DMCAG2AZZ02A Drive Board Modular Assembly is not the original product of its specific Mark V Series functional role; that would be the DS215DMCAG2 parent Drive Board Module notably not making use of this DS215DMCAG2AZZ02A PCB's A-rated primary functional revision and optional software package.

Hardware Tips and Specifications

The DS215DMCAG2AZZ02A is a Drive Board module.  Like other DS215 boards, the DS215DMCAG2AZZ02A offers additional firmware or hardware as compared to a like-named DS200 board. The DS215DMCAG2AZZ02A can be easily mounted using factory-made drill holes located in each board corner; each one of these factory-drilled installation holes should be ringed with an insulated material in observance of potentially-present damaging DS215DMCAG2AZZ02A Board surface voltages. Additional drill holes are located along DS215DMCAG2AZZ02A board edges and within the body of the board. The edges of the unit are marked with lettering and/or numbering for easy alignment and carries several codes for identification purposes. The DS215DMCAG2AZZ02A is populated by a vertically mounted auxiliary board.  Located in the bottom left corner of the board, the auxiliary is placed next to the location of a second optional auxiliary board that mounts parallel to the surface of the board. While the true identity of this DS215DMCAG2AZZ02A Mark V Turbine Control System Series product's attached daughterboard has been lost due to this DS215DMCAG2AZZ02A PCB's attribution as a legacy series product yielding a low availability of instructional documentation, it can be theorized to exist as another Mark V Series product likely available here for both repair and replacement. Given the fact that this DS215DMCAG2AZZ02A PCB belongs to a legacy product series, the DS215DMCAG2AZZ02A functional product number itself can be considered a strong primary source of DS215DMCAG2AZZ02A Board hardware information, coding for various general details in a series of functional naming chunks. For instance, the DS215DMCAG2AZZ02A functional product number starts with the dual-functional DS215 series tag describing this DS215DMCAG2AZZ02A PCB's special motherboard assembly status as well as its domestic original manufacture location. Some of the other relevant details revealed through functional product number include this DS215DMCAG2AZZ02A Board's:

  • DMCA functional product abbreviation
  • Group 2 Mark V Series product grouping
  • Normal PCB protective coating
  • A-rated functional product revision
  • Optional attached software package

The DS215DMCAG2AZZ02A has multiple connectors, including a single female vertical connector, four male vertical pin cable connectors, and three header connectors. The board has two heat sinks, an inductor coil, fourteen jumper switches, fuse components, a push-button reset switch, LED indicators,  and transistors.  It carries over fifty integrated circuits, over twenty resistor network arrays, and various diodes, resistors, and capacitors made from materials including polyester vinyl, ceramic, and aluminum or tantalum electrolytic.  For additional information, including important information about handling and installation, please consult tech support products from GE like manuals and data sheets. Before making any final purchase decision on this DS215DMCAG2AZZ02A Mark V Turbine Control System Series product offering, it is critically important to consider that its originally-introduced performance specifications and basic dimensions have likely been impacted as a result of its special Mark V Series assembly's specific adoption of a singular A-rated functional revision and an optional software package as well.
