This DS2020UCOCN1G1A OC2000 Keypad Display was manufactured by General Electric for the Mark V Series of turbine control products.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS2020UCOCN1G1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS2020UCOCN1G1A
  • SKU: DS2020UCOCN1G1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS2020UCOCN1G1A Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS2020UCOCN1G1A
Functional Description OC2000 Keypad Display
Functional Acronym UCOC
PCB Coating Style Normal Coating
Assembly Type DS2020 Special Assembly
Revision Quantity 1 Revision

About the DS2020UCOCN1G1A

The DS2020UCOCN1G1A from General Electric is an N1 OC2000 display. This front mounting turbine management panel fits within General Electric’s Mark V Speedtronic turbine control system. The MKV can be used for the management of industrial steam or gas turbine systems and was one of the more advanced Speedtronic control systems released by GE from the 1960s onward (Mark I-Mark VIe). Please be sure to order the correct version of this panel; we have several UCOC displays in stock with minor variations between them. The original OC2000 Keypad Display manufactured for use in General Electric's Mark V Series is the DS2020UCOCN1 parent printed circuit board missing this DS2020UCOCN1G1A product's significant product revision. This DS2020UCOCN1G1A printed circuit board product offering really exists as more of a Mark V Series modular assembly, as indicated by the presence of the DS2020 series tag at the very beginning of the DS2020UCOCN1G1A functional product number.

Hardware Tips and Specifications

The DS2020UCOCN1G1A modular assembly featured here typically is used in conjunction with the transformer assembly, DS2020DACAG1. More information about that component can be found on our website, as the DS2020DACAG1 board and revised options are additionally available for repair and replacement. Many specific hardware component inclusions and specifications contribute to this DS2020UCOCN1G1A PCB's functional status within its greater Mark V Series automated drives assembly. The DS2020UCOCN1G1 is built with a front display that uses multiple membrane switches; these are organized into easily-used and understood sections. The sections include a readout for Gen. voltage, frequency, current, Mwatts, MVars, and power failure.  A second readout in the assembly of this DS2020UCOCN1G1A OC2000 Display offers C1, C2, and P faults as well as field volts, amps, and temperature. Additional sections are devoted to local control and diagnostic readout, as well as another that is labeled “OC2000.”  Some of the sections of membrane switches in this DS2020UCOCN1G1A PCB's assembly include membrane switches with a numeric keyboard, an enter key, a help key, an escape/clear key, as well as keys for starting, stopping, and enabling the system.

The bottom rear panel of the unit is designed to allow airflow to the internal components, which helps maintain a proper temperature.  Additionally, the rear panel includes connectors like Ethernet, terminal connectors, and an RS-232 connector. Finally, this DS2020UCOCN1G1A board's external cover has a tophat flange on either side that has been drilled to allow for mounting. Every factory-drilled installation hole in the assembly of this DS2020UCOCN1G1A PCB should have been insulated in observance of potentially-present damaging surface voltages. This DS2020UCOCN1G1A, while not as well-documented online in original General Electric and Mark V Series instructional manuals as we might have hoped, still offers additional product-specific hardware information through an analysis of its intuitive DS2020UCOCN1G1A functional product number. The DS2020UCOCN1G1A functional part number begins with the DS2020 series tag detailing this DS2020UCOCN1G1A PCB's special modular assembly type and domestic location of manufacture. This series tag is followed in the DS2020UCOCN1G1A functional product number by the UCOC functional product abbreviation, which itself is followed by functional product number components detailing this DS2020UCOCN1G1A PCB's N-style of PCB coating, group 1 Mark V Series grouping, and special G1A-rated product revision, which surely alters the DS2020UCOCN1G1A PCB from the original performance specifications outlined for its DS2020UCOCN1 parent modular assembly.

Frequently Asked Questions about DS2020UCOCN1G1A

What is the purpose of this DS2020UCOCN1G1A product offering's UCOC functional product abbreviation?

The UCOC functional product abbreviation specific to this DS2020UCOCN1G1A PCB is a shortened representation of the DS2020UCOCN1G1A functional product number, developed for promotional and conversational efficiency.

What part of the DS2020UCOCN1G1A functional product number reveals this DS2020UCOCN1G1A PCB's group one Mark V Series grouping?

The G1 series grouping tag in the DS2020UCOCN1G1A functional product number reveals this DS2020UCOCN1G1A' PCB's normal style of PCB coating and group one Mark V Series grouping.

Reviews For DS2020UCOCN1G1A

Internal Review
(5.0)

This DS2020UCOCN1G1A OC2000 Keypad Display is a unique and boldly-equipped model of printed circuit board assembly developed for use in the Mark V Turbine Control System Series. This product's functional description as an OC2000 Keypad Display points to its allegiance to both the Mark V Series and the OC2000 subseries, which makes sense given this DS2020UCOCN1G1A product offering's special N style of PCB coating and modular special assembly type. This DS2020UCOCN1G1A PCB is available today for repair and replacement. - AX Control Lead Technician

Repair Services For DS2020UCOCN1G1A

Type Lead Time Price Action
Repair Service 1-2 weeks $1345

Our highly skilled technicians can repair your DS2020UCOCN1G1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
