About the DS2020FECNRX020A
This DS2020FECNRX020A modular assembly, as dictated in the brief functional product description above, was originally designed and produced by General Electric, specifically for placement in this Mark V Turbine Control System Series. The Mark V Series that this DS2020FECNRX020A Device belongs to is rather self-explanatory; as it has a series of set specific applications in the control and management systems of compatible and popular wind, gas, and steam turbine automated drive assemblies. This DS2020FECNRX020A device's greater Mark V Series, while pertinent to some more recently-devised applications, must be considered an obsolete product series as a whole as it exists as a manufacturer-discontinued legacy General Electric product series. This DS2020FECNRX020A product's greater Mark V Series, while generally obsolete as a legacy product series, is still something of a highly-esteemed General Electric Mark product series on the general automated industrial market, as it exists as one of the final-developed Mark product series to make use of the patented Speedtronic control system technology across a range of its various offerings.
Hardware Tips and Specifications
The GE Field Exciter Board DS2020FECNRX020A features 7 jumpers and 2 terminal blocks with 3 terminals on each. The jumpers are identified as JP1 through JP7. The GE Line Protection Board DS2020FECNRX020A also contains multiple prong-type connectors. The board is installed on standoffs on another component of the drive. The signal wires that connect to the board originate on the component to which it is attached. The component that this DS2020FECNRX020A Field Exciter Module's base circuit board is attached to is a sturdy metallic backplane designed to aid in this DS2020FECNRX020A product's installation in its greater Mark V Series automated drive assembly. Generally, voltage suppression and limitation in the special modular assembly of this DS2020FECNRX020A Field Exciter Module will be handled through the incorporation of basic Mark V Series-standardized hardware components into its assembly; including different styles of capacitors, transistors, resistors, and integrated circuits. As indicated in the DS2020FECNRX020A Data Sheet attached above in our manuals tab for your convenience, this DS2020FECNRX020A Module provides valid excitation for an up to 24 A motor field, and operates with both NRX non-plugging or NRP plugging styles of non-reversing field supplies. This DS2020FECNRX020A PCB is not the originally-introduced product of its specific functional role within the Mark V Series; that would be the DS2020FECNRX020 parent Field Exciter Module not making use of this DS2020FECNRX020A PCB's singular A-rated functional product revision.
The GE Field Exciter Board DS2020FECNRX020A is shipped to your location as one completely assembled unit and because of the weight of the unit it requires some special consideration. The weight of the unit makes it subject to damage in transit so care must be taken that you inspect the shipping carton for damage. When you receive the box first look at the shipping label and write down the model number, serial number, and other important information. Keep it in a safe place with the other important documentation about the device so that you have it on hand if you have a need to call for service or support. Make sure the model number matches what you ordered. Visually inspect the box to see if it has been bashed in or dented. Also look for signs of water damage. That is, has water or another liquid dripped on the box or has the box sat in a puddle of water. Open the box and put to one side any packing material you find on top of the device. Lift the unit out and rest it on a clean sturdy surface. As a now-discontinued Mark V Legacy Series product, this DS2020FECNRX020A Field Supply Module's originally-printed instructional manual materials are largely unavailable online for the purposes of this DS2020FECNRX020A device's personalized product page. With this being true, the DS2020FECNRX020A functional product number itself can be adopted as a strong supplementary source of DS2020FECNRX020A Board details; coding for these in a series of consecutive functional naming chunks. For instance, the DS2020FECNRX020A functional product number is started by the dual-functional DS2020 series tag delegating this DS2020FECNRX020A device's special modular assembly version and its domestic original manufacture location. Some of the other relevant information revealed in the DS2020FECNRX020A functional product number includes this PCB's:
- FECN functional product acronym
- RX020 style of PCB protection
- A-rated primary functional revision
