GE LAN Power Supply Circuit Board DS200UPLAG1BDA

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a DS200UPLAG1BDA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200UPLAG1BDA
  • SKU: DS200UPLAG1BDAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200UPLAG1BDA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
GE LAN Power Supply Circuit Board DS200UPLAG1BDA

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a DS200UPLAG1BDA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200UPLAG1BDA
  • SKU: DS200UPLAG1BDAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200UPLAG1BDA Technical Specifications

Manufacturer GE General Electric
Part Number DS200UPLAG1BDA
Product Type LAN Power Supply Circuit
Series Mark V

Product Description

The GE LAN Power Supply Circuit Board DS200UPLAG1BDA contains two 26-pin connectors, 1 fuse, and 1 toggle switch. The board also has 1 reset button and 1 8-pin connector. The GE LAN Power Supply Circuit Board DS200UPLAG1BDA also features two 26-pin connectors that send and receive control signals through a ribbon cable. The ribbon cable is made up of multiple fine wires that are connected to a plastic connector. The connector plugs into the pins in the connector on the board.

The fine wires are easily broken or disconnected from the ribbon cable so it is best to limit the amount of handling you do to the ribbon cables. Also, when you disconnect the ribbon cable from the board, refrain from holding the ribbon cable portion of the cable. Instead, hold the plastic connector and with one hand. With the other hand, brace the board to keep it from moving and pull the connector from the board. This limits the stress you put on the ribbon cable and reduces the opportunity for breakage.

The board is populated with 17 jumpers and 16 switches. Some of the jumpers and switches are set at the factory and are only for use at the factory for testing purposes. Others can be used to configure the board for use by the site. The information provided with the board provides more information. However, when you replace the board, it is best practice to set the jumpers and switches on the replacement board exactly as they are set on the old board.

Repair Services For DS200UPLAG1BDA

Type Lead Time Price Action
Repair Service 1-2 weeks $785

Our highly skilled technicians can repair your DS200UPLAG1BDA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
