DS200UPLAG1B

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.94 (16)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.94 (16)
  • Click a star to rate this product
The DS200UPLAG1B LAN Power Supply Card was manufactured for General Electric's Mark V Series of turbine control systems.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DS200UPLAG1B to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200UPLAG1B
  • SKU: DS200UPLAG1BGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200UPLAG1B Technical Specifications

Manufacturer General Electric
Series Mark V
Part Number DS200UPLAG1B
Functional Acronym UPLA
Functional Description LAN Power Supply Card
PCB Coating Normal Coating
Functional Revision 1 B

About the DS200UPLAG1B

This DS200UPLAG1B printed circuit board was originally manufactured for placement in General Electric's Mark V Turbine Control System Series, as revealed above. This DS200UPLAG1B printed circuit board or PCB for short's greater Mark V Series has specific applications in the management and control systems of compatible steam, wind and gas turbine automated drive assemblies, and is considered to exist as a now-obsolete General Electric legacy product series given its manufacturing discontinuation in the years following its original release. This DS200UPLAG1B printed circuit board or PCB for short's Mark V Series, while a legacy series, is also one of the final General Electric Mark product series to make use of their patented Speedtronic control system technology first seen with the rollout of the Mark I in the late 1960s. This DS200UPLAG1B printed circuit board is truly better-definable as an LAN Power Supply Card, although the original product of this specific functional role to appear in the Mark V Series is the DS200UPLAG1 parent printed circuit board missing this DS200UPLAG1B product's revision table.

Hardware Tips and Specifications

As with any printed circuit board available to our new and reconditioned inventory of Mark V Series products, the functionality of this DS200UPLAG1B PCB is achieved through its own specific series of functionality-introducing hardware components and component specifications. The GE LAN Power Supply Circuit Board DS200UPLAG1B contains two 26-pin connectors, 1 fuse, and 1 toggle switch. The board also has 1 reset button and 1 8-pin connector.  The reset button on the GE LAN Power Supply Circuit Board DS200UPLAG1B can be used to restart the board when the board begins to behave erratically or have intermittent problems during normal operation. It enables you to restart the board without restarting the drive and so requires less time and expense. Because of the high-voltage conditions in the drive, only qualified persons should use the restart button. Open the board cabinet on the drive and locate the restart button on the board. Without touching any other components, press the button for a few seconds. Then, release the button. The board will restart and will resume normal operation. The board is 8.5 inches by 11 inches and is a standard size of boards that are installed in the drive. The DS200UPLAG1B boards are installed in the rack in the Mark V Series board cabinet and are secured in place with screws in each of the four corners. Matching holes are in the rack and enable you to align the holes and secure the board with screws. Before you install the DS200UPLAG1B LAN Power Supply board consider that the board has 17 jumpers and 16 switches that are used to configure the board. The switches are arranged in two blocks of 8 switches and have an ON and OFF position. The jumpers can be re-positioned over another set of pins.

The above paragraph features a disproportionate amount of DS200UPLAG1B printed circuit board installation-geared hardware procedures and requirements. While these instructions are certainly crucial to follow during any attempted DS200UPLAG1B board installation, their presence on this DS200UPLAG1B personalized product page is really more telling of a lack of other DS200UPLAG1B board-specific hardware details available to its originally-printed instructional manual materials. With this in mind, the DS200UPLAG1B functional product number is truly important to the DS200UPLAG1B board as it reveals several of its core hardware details, beginning with the DS200 series tag at the beginning of the DS200UPLAG1B functional product number with dual naming responsibilities. The DS200 series tag that starts off the DS200UPLAG1B functional product number is telling of this DS200UPLAG1B PCB's normal Mark V Series assembly and domestic manufacture location. Some of the other hardware details in the DS200UPLAG1B functional product number include this DS200UPLAG1B LAN Power Supply Card's:

  • UPLA functional product abbreviation
  • Normal style of PCB surface coating
  • Group one Mark V Series grouping
  • B-rated functional product revision

Frequently Asked Questions about DS200UPLAG1B

What does this DS200UPLAG1B PCB's normal style of PCB coating entail?

The normal style of PCB coating made to this DS200UPLAG1B printed circuit board is a thick, rudimentary layer of daily wear and tear protection that envelops and protects individual DS200UPLAG1B board elements on a functional priority basis.

Would this DS200UPLAG1B LAN Power Supply Card be protected by any warranty upon my purchase here?

Yes. Immediately following your original purchase from AX Control, this DS200UPLAG1B PCB and many others would be considered protected by our guaranteed three-year warranty.

Reviews For DS200UPLAG1B

Internal Review
(5.0)

This DS200UPLAG1B printed circuit board, as explained twice above, was manufactured to have specific applications in wind, steam, and gas turbine automated drive assemblies; applications it should be well-reinforced for through its series of voltage-limiting hardware components and its thick PCB protective layer. This DS200UPLAG1B board has the somewhat-uncommon B-rated functional revision, and is available for repair or replacement today. - AX Control Lead Technician

Repair Services For DS200UPLAG1B

Type Lead Time Price Action
Repair Service 1-2 weeks $745

Our highly skilled technicians can repair your DS200UPLAG1B. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
