This DS200TCQCG1AHD Analog IO Expander Board was manufactured for General Electric's Mark V Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200TCQCG1AHD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200TCQCG1AHD
  • SKU: DS200TCQCG1AHDGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200TCQCG1AHD Technical Specifications

Original Manufacturer General Electric
Series Mark V Speedtronic
Functional Part Number DS200TCQCG1AHD
Functional Acronym TCQC
Revision Quantity 3 Revisions
Backwards-Compatibility 1st two revisions
Mark V Series Grouping Group 1

About the DS200TCQCG1AHD

Hardware Tips and Specifications

The GE RST Overflow Board DS200TCQCG1AHD is populated with 24 jumpers and 3 40-pin connectors. It also has 3 34-pin connectors and 1 16-pin connector. The ID assigned to the 16-pin connector is JC. The IDs assigned to the 40-pin connectors are JFF, JE, and 6PL. The 24 jumpers on the GE RST Overflow Board DS200TCQCG1AHD play an important role in the configuration of the board. The jumpers have two positions on which the installer can set the jumpers.

Depending on the selection, the board will process information differently. The jumpers are defined as:

  • 3 pin jumpers
  • cover pins 1 and 2 or pins 2 and 3
  • an electrical contact between the two pins it covers
  • not set by the installer but are used by the factory during product testing
  • set before the board is installed in the drive

To set the jumpers, arrange the board on a clean, dry, and sturdy work space and place a static protective material under the board. This might be the static protective bag the board was shipped in.


DS200TCQCG1AHD Product Number Analysis

The DS200TCQCG1AHD functional product number itself can be identified as a primary source of DS200TCQCG1AHD Board hardware information, as it codes for specific board details in a set of consecutive functional naming elements. For example, the DS200TCQCG1AHD functional product number begins with the dual-functional DS200 series tag delegating this DS200TCQCG1AHD PCB's normal Mark V Series assembly as well as its domestic location of original manufacture. Some of the other relevant hardware details revealed in the DS200TCQCG1AHD functional product number include this PCB's:

  • TCQC functional abbreviation
  • Normal PCB coating style
  • Group one Mark V Series product grouping
  • Three-fold revision history

Frequently Asked Questions about DS200TCQCG1AHD

Which part of the DS200TCQCG1AHD functional product number reveals this DS200TCQCG1AHD PCB's group one Mark V Series product grouping?

This DS200TCQCG1AHD PCB's G1 series grouping tag delegating this DS200TCQCG1AHD PCB's normal PCB coating style is dual-functional as it also reveals the DS200TCQCG1AHD PCB's group one Mark V Series product grouping.

What is the purpose of the TCQC functional product abbreviation?

The TCQC product abbreviation was designed by General Electric to exist as a functional shorthand conversational or promotional shorthand alternative to the lengthy DS200TCQCG1AHD functional product number.

Reviews For DS200TCQCG1AHD

Internal Review
(5.0)

This DS200TCQCG1AHD Analog IO Expander Board or Analog Input/Output Expander Board is an integral part of General Electric's Mark V Turbine Control System Series automated drive, as evidenced in part by its normal Mark V Series assembly's acceptance of a full range of three product revisions including the seldom-seen H-rated secondary functional revision and the uncommon D-rated artwork configuration revision as well. This DS200TCQCG1AHD device is available right here today with both repair and replacement options. - AX Control Lead Technician

Repair Services For DS200TCQCG1AHD

Type Lead Time Price Action
Repair Service 1-2 weeks $680

Our highly skilled technicians can repair your DS200TCQCG1AHD. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
