The DS200TCQBF1BAD Software PROM Set

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200TCQBF1BAD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200TCQBF1BAD
  • SKU: GBTC-18531
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200TCQBF1BAD Technical Specifications

Manufacturer General Electric
Series Mark V
Part Number DS200TCQBF1BAD
Functional Acronym TCQB
Functional Description Software PROM Set
PCB Coating F-style PCB coating
Functional Revision 1 B
Functional Revision 2 A
Artwork Revision D

About the DS200TCQBF1BAD

This DS200TCQBF1BAD printed circuit board or PCB for short is not the originally-manufactured product of its specific Mark V Series automated drive assembly; that would be the DS200TCQBF1 parent Software PROM Set not making use of this DS200TCQBF1BAD product's three significant product revisions rated at grades of B, A, and D, respectively. The DS200TCQBF1BAD is a large board that is covered with board components. The board has:

  • two relays located side-by-side
  • over a dozen jumper switches
  • multiple connectors, including:
    • three vertical pin cable connectors
    • a header connector
  • over seventy integrated circuits
    • at least five FPGA (field programmable gate arrays)
    • several EPROMs
    • chips designed for other processes

The board has metal film resistors, resistor network arrays, numerous types of capacitors, diodes, and other board components; most of these components are Mark V Series-standardized voltage-limiting hardware components utilized in voltage suppression.


DS200TCQBF1BAD PCB Number Broken Down

For a more detailed description of the DS200TCQBF1BAD, including a step-by-step description of proper installation procedures and recommended handling precautions, please refer to technical support products from GE like manuals or user guides. AX Control offers an automatic extended warranty on every GE PCB purchased from our inventory at no extra cost to you. For more information, talk to our team today. This DS200TCQBF1BAD functional product number is started by the dual-functional DS200 series tag delegating this DS200TCQBF1BAD PCB's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other relevant hardware details revealed through use of this DS200TCQBF1BAD PCB's functional product number includes its:

  • TCQB functional acronym
  • F-style of PCB coating
  • Group one Mark V Series product grouping
  • B-rated primary functional revision
  • A-rated secondary functional revision
  • D-rated artwork configuration revision

Frequently Asked Questions about DS200TCQBF1BAD

Are this DS200TCQBF1BAD PCB's three significant revisions backwards-compatible?

No. Only this DS200TCQBF1BAD PCB's first two functional-style product revisions can be considered backwards-compatible.

Where specifically was this DS200TCQBF1BAD PCB manufactured?

This DS200TCQBF1BAD PCB was originally manufactured in General Electric's Salem, Virginia factory plant location.

Reviews For DS200TCQBF1BAD

Internal Review
(5.0)

This DS200TCQBF1BAD Software PROM Set is an atypical Mark V Turbine Control System Series product, as it exists as a protective plastic case enclosing two individual PROM Module components, which exist as small printed circuit cards. This DS200TCQBF1BAD PCB's F-style PCB protective coating is simply a reference to this protective enclosure. This DS200TCQBF1BAD PCB belongs to the most-common second grouping of Mark V Series products, and is highly voltage-sensitive, as indicated by the bright orange sticker attached to it. - AX Control Lead Technician
