DS200TBSAG1AAA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.91 (11)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.91 (11)
  • Click a star to rate this product
This DS200TBSAG1AAA Serial Communication Termination Module was originally designed for mass production for General Electric's Mark V Series.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS200TBSAG1AAA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200TBSAG1AAA
  • SKU: DS200TBSAG1AAAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200TBSAG1AAA Technical Specifications

Original Manufacturer GE General Electric
Product Series Mark V
Functional Part Number DS200TBSAG1AAA
Functional Description Serial Communication Termination Module
Functional Abbreviation TBSA
PCB Coating Style Normal Coating
1st Functional Revision A
2nd Functional Revision A
Artwork Revision A

About the DS200TBSAG1AAA

This DS200TBSAG1AAA module is a part of the wide array of printed circuit boards that were developed as internal components for the Speedtronic Mark V series of industrial power generation turbine systems. The MK V was one in a series of industrial turbine control systems from General Electric. This DS200TBSAG1AAA unit specifically is one of the printed circuit boards that are designated as LM Transducer Circuit Boards.This Transducer PCB is designated under the alphanumeric code, DS200TBSAG1AAA, which describes the functionality of the product through several chunkable pieces. AX Control is able to provide the DS200TBSAG1AAA transducer circuit board as one of our in-stock DS200 circuit boards, available as both unused surplus units and re-optimized, reconditioned used modules.

Hardware Tips and Specifications

The DS200TBSAG1AAA LM Transducer Circuit Board unit is equipped with a transducer module to process the conversion of input energy from the turbine systems into the output energy required for the Mark V unit’s regulation and turbine monitoring capabilities. This is central to the normative functionality of this Mark V Series product, although several other crucial hardware components and component specifications work in tandem to achieve this PCB's originally-intended functionality. Some of the more obvious of these hardware elections exist in the series of different connectors available to the DS200TBSAG1AAA Circuit Board owner. Four total connector types can interface with this DS200TBSAG1AAA Serial Communication Termination Module, including:

  • The P3 TCSA-to-DLE 12 V dc power connector
  • The P4 TCSA-to-FMVED 12 V dc power connector
  • The P5 FMVED-to-UCPB communication channel connector
  • The P6 FMVED-to-UCPB communication channel connector.

As the eagle-eyed prospective PCB buyer may have noticed, the last two connectors in the assembly of this DS200TBSAG1AAA LM Transducer Circuit board have the exact same intended purposes; the only difference between these two connectors can safely be classified as their specific communication channels; the P5 connector deals with communication channels 1 and 2, while the P6 connector interfaces channels 3 and 4. Before making a purchase decision on this DS200TBSAG1AAA Serial Communication Termination Board, it is important to realize that this PCB from General Electric has a full three-fold revision history.

Frequently Asked Questions about DS200TBSAG1AAA

What type of significant product revisions does this DS200TBSAG1AAA Serial Communications Termination Board have?

This DS200TBSAG1AAA Serial Communications Termination Board has both two functional product revisions and one artwork product revision in its assembly, as signified by the final three A digits in the DS200TBSAG1AAA functional product number.

Does this DS200TBSAG1AAA PCB product feature any customizable hardware?

Yes. This DS200TBSAG1AAA Serial Communication Termination Board makes use of several manually-movable hardware jumpers in its assembly, with the purpose of selecting communication circuits for FMVED motor controller serial links.

Reviews For DS200TBSAG1AAA

Internal Review
(5.0)

This DS200TBSAG1AAA printed circuit board or DS200TBSAG1AAA Serial Communication Termination Module, as it is referred to in original General Electric instructional manual information, was originally designed and manufactured as a part of the Mark V Series of turbine control systems. The module status of this PCB product was more than likely influenced by this PCB's inclusion of a full range of possible revisions, and should remain well-protected under this Mark V Series offering's standard normal style of PCB protective coating. - AX Control Lead Technician

Repair Services For DS200TBSAG1AAA

Type Lead Time Price Action
Repair Service 1-2 weeks $1030

Our highly skilled technicians can repair your DS200TBSAG1AAA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

DS200TBSAG1AAA Manuals, White Papers, Data Sheets, and Troubleshooting
