The DS200SVMAG1A SRC Voltage Monitor Board

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DS200SVMAG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200SVMAG1A
  • SKU: GBTC-11560
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200SVMAG1A Technical Specifications

Original Manufacturer GE General Electric
Product Series Mark V
Functional Part Number DS200SVMAG1A
Functional Product Description SRC Voltage Monitor
Functional Abbreviation SVMA
PCB Coating Type Normal Coating
1st Functional Revision A

About the DS200SVMAG1A

The DS200SVMAG1A printed circuit board is built as an SCR Voltage Monitor card. This device:

  •  ensures that the Mark V control drive voltage intake monitoring
  • manually regulates said intake
  • prevents any excess voltage from surging the drive and causing any possible damage

DS200SVMAG1A Visual Inspection Qualities

This DS200SVMAG1A SRC Voltage Monitor Board is equipped by many of the standardized voltage-limiting hardware components unique to the Mark V Series, including various diodes, capacitors, and integrated circuits in its assembly, paired with the insulated normal style of PCB coating that covers the DS200SVMAG1A PCB's base circuit board with a thick rudimentarily-protective layer of chemically-applied coating. The normal style of printed circuit board coating specific to this DS200SVMAG1A product offering was discovered upon a thorough visual inspection of the product, which reveals other information including this DS200SVMAG1A product's:

  • Normal style of Mark V Turbine Control System Series assembly
  • Domestic location of original manufacture
  • SVMA functional product acronym
  • Normal style of PCB protective coating
  • Group one Mark V Series grouping
  • A-rated functional product revision

The A-rated product revision present in this DS200SVMAG1A SRC Voltage Monitor Board's assembly is considered a functional style of product revision as it makes noteworthy improvements to the original performance specifications and general functionality of the DS200SVMAG1 parent product without making any notable sacrifices for aesthetic or durability qualities. While generally attributable as a domestically-manufactured General Electric printed circuit board, this DS200SVMAG1A PCB's specific manufacture location can be defined as GE's Salem, Virginia factory plant location.


Frequently Asked Questions about DS200SVMAG1A

Would this DS200SVMAG1A SRC Voltage Monitor Board be equipped with any warranty following my purchase?

Yes. Immediately following your original purchase from AX Control, this DS200SVMAG1A product and many others would be considered protected by our guaranteed three-year PCB warranty.

Does this DS200SVMAG1A PCB's assembly feature any drilled installation holes?

Yes. The base circuit board of this DS200SVMAG1A product offering has been factory-drilled in several locations to facilitate safe and convenient installation, with each drill-hole being insulated.

Reviews For DS200SVMAG1A

Internal Review
(4.0)

This DS200SVMAG1A SRC Voltage Monitor Board is a General Electric Mark V Turbine Control System Series that is both not very well-documented or well-supported; offering a basic A-rated functional product revision and a notable absence of research-relevant instructional manuals. With that said, this DS200SVMAG1A product is well voltage-protected, and is available here today with both repair and replacement options available. - AX Control Lead Technician
