About the DS200SSBAG1B
This DS200SSBAG1B printed circuit board product offering, as mentioned before, was originally manufactured by General Electric, specifically for placement in their Mark V Turbine Control System Series. The Mark V Series that this DS200SSBAG1B printed circuit board or PCB for short belongs to, as exemplified through the included full extended series name, has specific applications in the management and control systems of popular and compatible wind, steam, and gas turbine automated drive assemblies. In addition to this DS200SSBAG1B PCB's Mark V Series' alternative energy-minded applications, it also exists as one of the final-developed General Electric Mark product series to incorporate the patented Speedtronic control system technology into many of its varied options. While this is true, the DS200SSBAG1B DC300 Drive Snubber Board's Mark V Series is not considered up to date, as it is a now-obsolete legacy product series discontinued by General Electric in one of the many years following its initial release. This DS200SSBAG1B PCB is not the originally-developed product of its specific Mark V Series functionality; that would be the DS200SSBAG1 parent DC300 Drive Snubber Board missing this DS200SSBAG1B device's singular, B-rated functional product revision.
Hardware Tips and Specifications
As with any product made available to our extensive new and reconditioned inventory of General Electric products here, this DS200SSBAG1B PCB makes use of its own particular series of functionality-inducing hardware components and component specifications. The GE DC300 Drive Snubber Board DS200SSBAG1B features one 2-pin connector, 3 capacitors, and four posts for attaching cables. Before you begin the replacement procedure keep in mind the following information. Only a qualified servicer can perform the replacement due to the high-current present in the drive when it is in operation. The servicer should understand the dangers and the guidelines to minimize the safety hazards. Inspect the area around the drive and clear the area of ungrounded electrical cords because they present a shock hazard. Also, clear the floor of any moisture or puddles or water because of the shock hazard. It is a good practice also to clear the area of debris that the servicer might trip over. The most important consideration is that the servicer should never work alone. This is to have someone nearby if an emergency condition exists and the associate can call for help or deliver aid, if possible. Also, the associate can assist with the replacement procedure.
The drive must have all voltage removed from it before the interior components can be touched. To do that, refer with someone that is familiar with the drive and how it was installed at the site. The best practice is to disable the power supplies by removing the fuses from it or in some other way taking it off line. Use a testing device to test for lmingpower in the drive. Some components store current even after the power supply is powered down. Wait a few seconds for power to escape the components before you test the drive. The above-included information in the textual portion of this DS200SSBAG1B PCB's personalized product page here is overwhelmingly reminiscent of this DS200SSBAG1B Device's installation and replacement procedures. While these procedures are certainly important to abide by, their presence on the DS200SSBAG1B functional product page here is more telling of this DS200SSBAG1B PCB's lack of online-available instructional documentation. With this lack being true, the DS200SSBAG1B functional product number itself can actually be identified as a primary source of DS200SSBAG1B Board hardware component and component specification information; coding for specific details in a amalgamation of specific functional naming sections. For example, the DS200SSBAG1B functional product number is started by the dual-functional DS200 series tag, which serves to describe this DS200SSBAG1B product's normal Mark V Series assembly version as well as its domestic original manufacture location. Some of the other relevant hardware details revealed in this DS200SSBAG1B PCB's functional product number includes its:
- SSBA functional product abbreviation
- Group one Mark V Series product grouping
- Normal style of PCB coating
- B-rated functional product revision
