The DS200SSBAG1ARP DC300 Drive Snubber Board was manufactured by General Electric for the Mark V series of turbine control systems.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS200SSBAG1ARP to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200SSBAG1ARP
  • SKU: DS200SSBAG1ARPGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200SSBAG1ARP Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS200SSBAG1ARP
Functional Description Snubber Card
Functional Acronym SSBA
PCB Coating Normal Coating
Functional Revision 1 A
Functional Revision 2 R
Artwork Revision P

About the DS200SSBAG1ARP

This DS200SSBAG1ARP printed circuit board is better-definable by its original instructional manual-specified functional product description as a DC300 Drive Snubber Board, as explained above. This DS200SSBAG1ARP model of Drive Snubber Board is not the original Drive Snubber Board manufactured by General Electric for the Mark V Turbine Control System Series, as it is edited from the original DS200SSBAG1 parent printed circuit board through its inclusion of two functional product revisions and a third artwork configuration revision. The Mark V Series that this DS200SSBAG1ARP DC300 Drive Snubber Board belongs to is characterized by its usage of the General Electric-patented Speedtronic technology in its internal assembly, which allows compatibility with other components in the Mark V Series automated drive assembly.

Hardware Tips and Specifications

This DS200SSBAG1ARP DC300 Drive Snubber Board is a General Electric Mark V Series product offering with its own series of set hardware components and component specifications. The GE DC300 Drive Snubber Board DS200SSBAG1ARP features one 2-pin connector, 3 capacitors, and four posts for attaching cables. Three of the four posts on the GE DC300 Drive Snubber Board DS200SSBAG1ARP are designed to connect to the three cables attached to a component on the board. When you receive the original board from the factory, the printed materials describe how to attach the three cables to the terminals; these instructions are crucial to follow given this DS200SSBAG1ARP PCB's status as a static-sensitive GE printed circuit board. The fourth terminal in the assembly of this DS200SSBAG1ARP PCB is connected to a wire present in the drive.

Given the fact that this DS200SSBAG1ARP DC300 Drive Snubber Board is generally not well-detailed in original Mark V Series instructional manual documentation, the DS200SSBAG1ARP functional product number is a strong source of this SSBA-abbreviated board's pertinent hardware information. For starters, the DS200SSBAG1ARP functional product number begins with the DS200 series tag detailing this DS200SSBAG1ARP product's normal Mark V Series assembly version and domestic location of original manufacture. This tag is followed in the DS200SSBAG1ARP product number by an instance of the SSBA functional acronym, which was created to exist as a functional conversational or promotional representation of the lengthy DS200SSBAG1ARP product number. This is followed in the product number by the G1 series grouping tag, which also has dual naming responisbilities for this Mark V Series PCB. The G1 series grouping tag identifies this DS200SSBAG1ARP DC300 Drive Snubber Board as a Mark V Series group one product with a normal style of protective printed circuit board coating. The final three alphanumeric digits at the end of this DS200SSBAG1ARP product number inform the interpreter of this DS200SSBAG1ARP PCB's three-fold revision history.

Frequently Asked Questions about DS200SSBAG1ARP

What drives is DS200SSBAG1ARP used with?
DS200SSBAG1ARP is used with DC300/2000 drives.
What kind of batteries are on a DS200SSBAG1ARP?
DS200SSBAG1ARP has two batteries. DS200SSBAG1ARP's batteries are AZ CAP K90017-437 batteries. These batteries on DS200SSBAG1ARP are 660 VAC.
How many pins is DS200SSBAG1ARP's connector?
DS200SSBAG1ARP has a 2-pin FCPL connector.

Reviews For DS200SSBAG1ARP

Internal Review
(5.0)

This General Electric Mark V Turbine Control System Series product is unique in a number of various hardware specifications, but that's not to say it isn't a well-supported General Electric printed circuit board. This DS200SSBAG1ARP DC300 Drive Snubber Board is additionally considered a member of the DC300 subseries, as evidenced by its inclusion in this PCB's official functional description. This DS200SSBAG1ARP DC300 Drive Snubber Board features a seldom-seen R-rated secondary functional product revision. - AX Control Lead Technician
