About the DS200SLCCG3AGH
This DS200SLCCG3AGH printed circuit board product offering from General Electric, as mentioned before, was originally designed and manufactured for a specific functional role in their Mark V Turbine Control System Series automated drive assembly as a LAN Communications Board. This DS200SLCCG3AGH, while existing as a LAN Communications Board, is not the originally-developed product of this specific functionality; that would be the DS200SLCCG3 parent LAN Communications Board missing this DS200SLCCG3AGH product's three significant product revisions. This DS200SLCCG3AGH PCB's greater Mark V Series is something of a rather self-explanatory product series based on its full extended series name, as it has a series of specific applications in the management and control systems of popular and compatible wind, steam, and gas turbine automated drive assemblies. This DS200SLCCG3AGH PCB's greater Mark V Series, while certainly a pertinent series to newer alternative energy applications, has to be considered obsolete as a whole, as it actually was discontinued for manufacture due to a retailer-recognized series-wide functional obsolescence in one of the many years following its initial release. This DS200SLCCG3AGH PCB's greater Mark V Series has something of a niche demand on the figurative automated industrial marketplace, as it exists as one of the lastly-developed Mark product series to make use of the patented Speedtronic control system technology.
Hardware Tips and Specifications
The DS200SLCCG3AGH is a LAN communication board from General Electric. This board is designed to fit into a Mark V Speedtronic system and is also compatible with a wide variety of GE drives and exciters. This board, when installed, provides process and interface functions with incoming LAN (local area network) communications. The DS200SLCCG3AGH is built with both isolated and non-isolated communications circuits. The board features several integrated circuits including FPGAs and EEPROMs. It also has an LED display located near the top third of the board that offers an alpha-numeric display. Inputs are typically done through an attached keypad. Given the fact that this DS200SLCCG3AGH printed circuit board product offering from General Electric is a member of a now-discontinued legacy product series, it is not offered alongside a plethora of originally-printed instructional manual documentation online. With this being the case, this DS200SLCCG3AGH PCB's functional product number itself becomes a primary source of DS200SLCCG3AGH Board hardware component and component specification information; coding for relevant DS200SLCCG3AGH details in a series of functional naming segments. For example, the DS200SLCCG3AGH functional product number begins with the dual-functional DS200 series tag delegating this DS200SLCCG3AGH PCB's normal Mark VSS Seire assembly an its domestic original nurturance location. Some of the other relevant hardware information revealed by way of this DS200SLCCG3AGH PCB's functional product number include its:
- SLCC functional product number
- Normal PCB coating style
- Group three Mark V Series product grouping
- A-rated primary functional revision
- G-rated secondary functional revision
- H-rated artwork configuration revision
Other board components on the DS200SLCCG3AGH include seven jumper switches and multiple jumper wires, resistor network arrays along with traditional resistors, capacitors, transistors, and diodes. The board also has multiple connectors, primarily male, that offer both right-angle and vertical connections. The board is factory drilled in the corners to allow for mounting options and is marked with references to allow for easy identification of components. It also has the board number and the GE logo printed on its surface. This board does not have an attached faceplate. For more detailed information about the board, its components, and proper installation techniques, please refer to OEM publications like manuals, data sheets and user guides that refer to the board. The primary manual for the DS200SLCCG3AGH board is GEI-100162. If this is no longer available to you AX Control may be able to provide access to a copy with your order. We protect all static sensitive boards during shipment with anti-static wrap.
