DS200SLCCG3AEE

Product Description

General Electric developed the DS200SLCCG3AEE as a local area network (LAN) communication board. This card was manufactured as a member of the Mark V series of replacement boards. Any number of drives and exciters across the GE brand are built to have this board installed in its drive cabinet. From this board the host drive is provided with required space for LAN communication signal interfacing.

Hardware Tips and Specifications

As with any similar Mark V Series product; this DS200SLCCG3AEE LAN Communication Card utilizes a number of product-specific hardware elements and hardware specifications to teach its intended functionality. The DS200SLCCG3AEE communication board’s integrated LAN control processor (LCP) filters signals received by the card. All program memory for the LCP is stored in the two EPROM memory cartridges attached to the board. The DS200SLCCG3AEE LAN Communication board also includes a dual ported RAM to provide interfacing space for the LCP and the host’s drive control board. Both isolated and nonisolated circuits are available for communication signals, and an attachable programmer keypad provides users with easy access to system diagnostics and settings. Additional performance specifications and hardware elements unique to this DS200SLCCG3AEE LAN Communication Card are available upon a simple inspection of this product's DS200SLCCG3AEE functional product number, which yields information such as:

• A normal Mark V assembly version
• A domestic manufacture location
• The SLCC functional acronym
• The normal PCB coating style
• A group 3 Mark V Series grouping
• three significant product revisions

Any product shipped by AX Control will be carefully protected by a static resistant plastic bag. Do not remove the product from its protective wrappings until all manufacturer provided installation parameters have been reviewed. Only trained personnel should be permitted to handle this drive board. The manual and datasheet for the DS200SLCCG3AEE LAN communication board contains a complete wiring and installation guide; General Electric originally provided this card with technical support.
