This DS200SLCCG1A General Electric LAN Communications Card was originally manufactured for the Mark V Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200SLCCG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200SLCCG1A
  • SKU: DS200SLCCG1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200SLCCG1A Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS200SLCCG1A
Functional Description LAN Communications Card
Instruction Manual GEI-100162
Functional Acronym SLCC
PCB Coating Normal Coating
Functional Revision 1 A

About the DS200SLCCG1A

The DS200SLCCG1A board was developed by General Electric as a local area network (LAN) communication card. The board is housed in the Mark V series of drive and exciter boards. It can be installed in drive and exciter cabinets across the GE brand. Installing the card provides a necessary communication medium needed for drive operation. As a G1 version of the board, this card includes the circuitries needed for both DLAN and ARCNET networks.

Hardware Tips and Specifications

Both isolated and nonisolated circuits are provided by the DS200SLCCG1A LAN communication card. Communications functions are filtered through the LAN control processor (LCP) integrated on to the board. Two removable EPROM memory cartridges provide the program storage for the LAN control processor or LCP. The DS200SLCCG1A LAN Communications board also includes dual ported RAM. This memory space provides the storage for communication between the LCP and an externally wired drive control board. An attachable alphanumeric keypad is also included with this DS200SLCCG1A Mark V Series drive component. This programmer provides users with access to board diagnostics and other system settings.

The DS200SLCCG1A functional product number itself is a valuable source of pertinent hardware component and specification information for this DS200SLCCG1A LAN Communications Board, given the relative unavailability of this DS200SLCCG1A PCB's original factory-printed instructional manual materials, at least on the internet. The DS200SLCCG1A functional product number begins with the DS200 series tag identifiying this DS200SLCCG1A PCB's normal assembly version and domestic location of original manufacture. This DS200 series tag is followed in the DS200SLCCG1A functional product number by the SLCC functional acronym, which was created to exist as a functional representation of the lengthy DS200SLCCG1A product number. Some of the other details revealed in the DS200SLCCG1A functional product number include its normal style of PCB protective coating, its group one Mark V Series product grouping, and the singular functionality-focused product revision made to the normal assembly of this Mark V Series product.

Frequently Asked Questions about DS200SLCCG1A

What connectors does DS200SLCCG1A have?
DS200SLCCG1A has 5 card connectors. The connectors that connect DS200SLCCG1A to other boards are: 2PL, 3PL, 10PL, ARCPL, and KPPL. 2PL on DS200SLCCG1A is the connector for +/-5, 15, and 24 VDC I/O between the power supply/interface board, the drive terminal board, simple drive terminal board, drive control card, and the DS200SLCCG1A. DS200SLCCG1A's 3PL connect is for DS200SLCCG1A inputs from the drive control card. Connector 10PL on DS200SLCCG1A is the I/O between LAN I/O terminal board and DS200SLCCG1A. Connector ARCPL on DS200SLCCG1A is the I/O between DLAN and ARCNET signals and DS200SLCCG1A, and KPPL is DS200SLCCG1A's I/O connection with the programmer module keypad.
How is DS200SLCCG1A mounted?
DS200SLCCG1A is mounted on four standoffs located on the SDCC. The programmer module plugs into connector KPPL on the DS200SLCCG1A and its keypad and snap over DS200SLCCG1A.
What type of jumpers does DS200SLCCG1A have?
DS200SLCCG1A has berg-type or manually moveable hardware jumpers and DS200SLCCG1A has wire jumpers, identified by a WJ nomenclature. The berg-type jumpers on DS200SLCCG1A are identified with a JP nomenclature.
Which manual is for DS200SLCCG1A?
The manual for DS200SLCCG1A is Manual GEI-100162. This manual is the GE Motors and Industrial Systems LAN Communications Card Manual. The manual provides a functional description of DS200SLCCG1A, application data for DS200SLCCG1A, and renewal/warranty replacement for DS200SLCCG1A.
