DS200SIOBH1AAA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.94 (16)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.94 (16)
  • Click a star to rate this product
This DS200SIOBH1AAA SC2000 VME I/O Board was manufactured by General Electric for use in their Mark V Series.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS200SIOBH1AAA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200SIOBH1AAA
  • SKU: DS200SIOBH1AAAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200SIOBH1AAA Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS200SIOBH1AAA
Functional Description VME Stand I/O Card
Functional Acronym SIOB
PCB Coating Conformal Coating
Functional Revision 1 A
Functional Revision 2 A
Artwork Revision A

About the DS200SIOBH1AAA

This DS200SIOBH1AAA printed circuit board product offering was originally manufactured by General Electric, for placement in their Mark V Series of turbine control systems and turbine control system component products. This DS200SIOBH1AAA PCB's greater Mark V Series is considered a legacy series, given its manufacturing discontinuation in the years following its initial release. This DS200SIOBH1AAA PCB's Mark V Series, while a General Electric legacy series, additionally exists as one of the final GE Mark product series to make use of their patented Speedtronic control system technology. This DS200SIOBH1AAA product offering is definable as an SC2000 VME I/O Board, given this functional description's placement in available General Electric instructional manual materials. The DS200SIOBH1AAA PCB, while definable as an SC2000 VME I/O Board in its own right, is not the originally-developed product of this functionality to exist within the Mark V; that would be the DS200SIOBH1 parent printed circuit board missing all three of this DS200SIOBH1AAA PCB's significant product revisions.

Hardware Tips and Specifications

The GE I/O Control Board DS200SIOBH1AAA features twenty jumpers and 3 switch blocks with 6 switches in each block for a total of 18 switches. It is also populated with one LED and one 40-pin connector. The LED on the GE I/O Control Board DS200SIOBH1AAA indicates the processing performed by the board and provides a first step if you are troubleshooting the board. While the drive is powered on you can visually check the status of the LED and understand the health of the board. If you find that the board is not working as you expected, you can use the troubleshooting tools on the drive to see if the board is not working or if other components in the drive are causing problems. In explaining the various hardware component inclusions and specifications made useful to this DS200SIOBH1AAA product offering, the DS200SIOBH1AAA functional product number itself can be considered crucial; given the limited availability of this DS200SIOBH1AAA PCB's instructional documentation. The DS200SIOBH1AAA functional product number begins with the dual-functional DS200 series tag delegating this DS200SIOBH1AAA PCB's normal Mark V Series assembly and its domestic location of original manufacture. Some of the other DS200SIOBH1AAA board relevant hardware details revealed in the DS200SIOBH1AAA functional product number includes this DS200SIOBH1AAA Board's:

  • SIOB functional product acronym
  • Conformal PCB coating style
  • Group one Mark V Series product grouping
  • A-rated primary functional revision
  • A-rated secondary functional revision
  • A-rated artwork configuration revision

To troubleshoot the board, you can use the control panel to initiate the troubleshooting tools on the drive. The control panel gives you access to the tools using the keyboard. The interface is menu-driven which means you make selections with the keys and also use the keys to scroll through the selections. One menu selection is to start the troubleshooting tool. The troubleshooting tool tests all the components in the drive and provides a diagnostic report that you can use to determine where the error resides. If you decide to replace the board, you have to examine the 20 jumpers and the 3 banks of switches and configure the board so that the jumpers and switches are set in the same positions. This will enable the new board to behave exactly like the defective board.

Frequently Asked Questions about DS200SIOBH1AAA

Are this DS200SIOBH1AAA SC2000 VME I/O Board's three significant revisions backwards-compatible?

No. This DS200SIOBH1AAA product offering's three total product revisions are not backwards-comaptible; only its first two are as they are both functional styles of Mark V Series revisions.

What does this DS200SIOBH1AAA printed circuit board's conformal PCB coating style involve?

The conformal PCB coating present on this DS200SIOBH1AAA PCB is a thin layer of exhaustive PCB protection and insulation applied to the entirety of this DS200SIOBH1AAA product's base circuit board.

Reviews For DS200SIOBH1AAA

Internal Review
(5.0)

This DS200SIOBH1AAA printed circuit board product offering from GE is another Mark V Turbine Control System Series product that is not well-documented in pertinent original manual materials. With this being true, the DS200SIOBH1AAA functional product number itself lends many DS200SIOBH1AAA board details as explained above, including this DS200SIOBH1AAA PCB's atypical H-rated conformal PCB coating style. - AX Control Lead Technician
