DS200SHVIG1BHD Technical Specifications

Instruction Manual GEI-100160
Manufacturer GE General Electric
Part Number DS200SHVIG1BHD
Product Type SCR High Voltage Interface Board
Series Mark V

Product Description

General Electric developed the DS200SHVIG1BHD as a SCR high voltage interface card for the Mark V board series. As a member of this optional and replacement card series, this board offers almost universal use across GE’s brand of drives and exciters. An interfacing medium between the power connect card, or PCCA, the instrumentation card, and the power supply board is provided with this board. Specifically, communications between the SCR bridge of the drive and the power supply are directed using this card.

DS200SHVIG1BHD works by receiving voltage signals and relaying them to the appropriate power or operation card. The board first receives voltage signals ranging as low as -500 mV and as high as 500 mV. All inputted signals are then converted with this board into differential frequencies ranging anywhere from 0 kHz all the way up to 500 kHz. Conversions are then sent from the interface board to the drive’s integrated power supply card. Attenuation capabilities of the drive are all built into the seventeen jumpers found on board. Each of the jumpers includes a 10:1 current transformer. Onboard diagnostics include three LED indicator lights that will alert users should any of the filter fuses found on the card blow out.

Any manufacturer provided installation parameters should be met by the user. Following all parameters will protect the integrity of the DS200SHVIG1BHD as well as its installed drive. Board integrity is also dependent upon users properly wiring the unit. The device’s manual as well as its datasheet houses a complete guide to installing this high voltage interface board. All members of the Mark V series were originally provided with technical support by their manufacturer, General Electric.

Our trusted sales staff at AX Control is happy to help with all of your GE drive needs. For prices on the DS200SHVIG1BHD board, or any other part or repair, please contact our office by phone or email.

Frequently Asked Questions about DS200SHVIG1BHD

What are some functions of the DS200SHVIG1BHD?
DS200SHVIG1BHD has several functions. DS200SHVIG1BHD converts shunt signals to differential-frequency outputs which are sent to the drive's power supply card, DS200SHVIG1BHD incorporates hardware jumper-selectable 10:1 current transformers to provide current attenuation capability, DS200SHVIG1BHD provide attenuation of both line and bridge voltages, and DS200SHVIG1BHD includes driver circuits for both standard and fast contactors.
How do I know if a fuse has blown on DS200SHVIG1BHD?
If a fuse blows on DS200SHVIG1BHD, there is an indicator light on DS200SHVIG1BHD that will be lit indicating the blown line filter fuse.
What type of board is DS200SHVIG1BHD?
DS200SHVIG1BHD is an SCR High Voltage Interface Board. DS200SHVIG1BHD is identified by the acronym SHVI.
Which manual pairs with DS200SHVIG1BHD?
The manual that pairs with DS200SHVIG1BHD is Manual GEI-100160. This manual is the GE Drive Systems Configurable Hardware SHVI SCR High Voltage Interface Board Manual. This manual is specific to DS200SHVIG1BHD and though this manual is mostly about DS200SHVIG1BHD hardware and replacement, this manual provides good general information about DS200SHVIG1BHD. For a copy of DS200SHVIG1BHD's manual, request manual GEI-100160.
