The DS200SHVIG1A SCR High Voltage Interface Board was manufactured by Reliance Electric for the Mark V Series.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS200SHVIG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200SHVIG1A
  • SKU: DS200SHVIG1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200SHVIG1A Technical Specifications

Abbreviation SHVI
Common Revisions DS200SHVIG1AAA
Configurable Hardware On-board Berg-type Jumpers
Manufacturer GE, General Electric, GE Drive Systems
Weight 2lbs
Series DC2000 Digital Adjustable Speed Drive
Part Number DS200SHVIG1A
Product Type SCR High Voltage Interface Board
Instruction Manual GEI-100160

About the DS200SHVIG1A

The DC2000 DS200SHVIG1A functions as a high voltage interface board and provides signals from the DC2000 drive's bridge to the DCFB or SDCI Board and the PCCA Card. Depending on the DC2000 drive type, the SHVI Board interfaces which whichever of the DCFB or SDCI that is installed. Similarly, the DS200SHVIG1A communicates with whichever revision of the power connect card (PCCA) is present in the drive model. The Mark V Series that this DS200SHVIG1A product offering can be considered a member of is a legacy General Electric product series, which means that its manufacture has been discontinued in the years following its initial release, leaving a notable gulf in its available online instructional manual materials. While this DS200SHVIG1A High Voltage Interface Board's greater Mark V Series is considered a legacy product series, it concurrently exists as one of the final General Electric Mark product series to utilize their patented Speedtronic control system technology. This specific DS200SHVIG1A model of High Voltage Interface Board is not the originally-developed product of its specific functionality; that would be the DS200SHVIG1 parent printed circuit board missing this DS200SHVIG1A PCB's common A-rated functional product revision.

Hardware Tips and Specifications

This DS200SHVIG1A printed circuit board, like any Mark V turbine control system series product available to our new and reconditioned products inventory, is introduced to its specific function within the Mark V Series though a series of necessary functionality-introducing hardware components and component specifications. Voltage signals to the device are passed through this board to be distributed accordingly. The DS200SHVIG1A works by converting voltage signals between -500 and 500 mV into differential frequencies ranging from 0 to 500 kHz. Once converted, the card sends the new frequency signals to the drive’s power supply card. On the board, seventeen user configurable jumpers are available and feature 10:1 current transformers. These configurable jumpers allow for attenuation capabilities depending on the position used during installation. Three onboard LED indicator lights visually alert users should any of the filter fuses blow out. General Electric provides a list of installation parameters that can be used in DC2000 Drive applications and specific reference the functionality of the DS200SHVIG1A..A guide to wiring and installation for the SHVI interface board can be found in the manual GEI-100160 as well as in supplemental datasheets. Part availability and repair pricing for this SCR High Voltage Interface Board can be obtained by contacting our sales staff by phone or email.

Unfortunately enough for the purposes of this DS200SHVIG1A product offering's personalized page here, the above information represents about the extent of hardware tips and specifications gleanable from a complete analysis of this DS200SHVIG1A product's existing instructional manual materials. With this being said, the DS200SHVIG1A functional product number, developed by General Electric, can be considered a strong source of DS200SHVIG1A board-pertinent hardware component and component specification information, beginning with its DS200 series tag holding dual naming responsibilities. The DS200 series tag at the very beginning of the DS200SHVIG1A functional product number describes this DS200SHVIG1A High Voltage Interface Board's domestic original manufacture location as well as its normal style of Mark V Series assembly. Some of the other DS200SHVIG1A-board-specific details revealed through the DS200SHVIG1A functional product number include this DS200SHVIG1A PCB's:

  • SHVI functional product abbreviation
  • Normal PCB coating style
  • Group one Mark V Series product grouping
  • A-rated primary functional revision.

Frequently Asked Questions about DS200SHVIG1A

What does DS200SHVIG1A do to shunt signals?
DS200SHVIG1A converts -500 mV to 500 mV shunt signals to 0 to 500 kHz differential-frequency outputs. These outputs created by DS200SHVIG1A are sent to the drive's power supply card.
What type of attenuation does DS200SHVIG1A provide?
DS200SHVIG1A provides attenuation of both line and bridge voltages.
What is DS200SHVIG1A an interface for?
DS200SHVIG1A provides an interface for signals from the drive's SCR bridge to the drive's power supply and instrumentation card, and to the PCCA.
Where can I find the manual for DS200SHVIG1A?
The GEI-100160 Manual can be found under the manuals tab on our AX Control website. Additional datasheets and troubleshooting documentation regarding the SHVI board will be added under the same section as it is posted from our internal library. The GEI-100160 manual includes board identification, hardware adjustments, and a board layout diagram.

Reviews For DS200SHVIG1A

Internal Review
(5.0)

The DS200SHVIG1A installation process is not overly complicated or time consuming as it requires the user primarily to ensure the configurable jumpers match the application specific positions in their documentation. The biggest challenge currently is locating available surplus for the "A" revision of this SHVI board. This DS200SHVIG1A printed circuit board should still exists as a well-protected Mark V Series product offering, given its possession of a thick rudimentary base layer of normal-style PCB protective coating. - AX Control Lead Technician
