About the DS200SHCAG1BAA
This piece of circuitry is a part of a series of printed circuit boards, the DS200 Mark V Turbine Control System series, from General Electric. These printed circuit boards are designed as integral internal parts of GE’s series of control drives for power generator turbines, as evidenced partially through the above-included full extended series name. This DS200 component is designated as the DS200SHCAG1BAA, and is outfitted to operate as a Turbine Energy Shunt Connector Board.
This DS200SHCAG1BAA device's greater Mark V Series attracts a niche demand on the greater figurative automated industrial marketplace, as it exists as one of the lastly-developed GE Mark product series to make use of the patented Speedtronic control system technology first released in the mid to later 1960s for use in the initial Mark I Series.
Hardware Tips and Specifications
The DS200SHCAG1BAA Turbine Energy Shunt Connector Board is able to be easily mounted into a Speedtronic Mark V turbine control unit. The Speedtronic drives are outfitted to provide state of the art control and management to gas and steam powered turbines, and provide operators with diagnostics and alter the turbine’s performance to prevent any damaging issues, such as overheating or the loss of the turbine’s oil.
This DS200SHCAG1BAA device is not actually the originally-developed product of its specific Mark V Series functionality; that would be the DS200SHCAG1 parent Shunt Connector Board missing this DS200SHCAG1BAA PCB's three-fold revision history.
Generally, this DS200SHCAG1BAA Mark V Series printed circuit board product offering's voltage suppression involves its standard acceptance of a Mark V Series-streamlined gathering voltage-limiting hardware components and component specifications. Some of this DS200SHCAG1BAA PCB's voltage-geared hardware components may include various forms and iterations of Mark V Series capacitors, diodes, rectifiers, transistors, and integrated circuits.
The DS200SHCAG1BAA functional product number may in this instance serve as a great supplementary source of DS200SHCAG1BAA Board hardware component and component specification information, as it codes for relevant DS200SHCAG1BAA Board details in a set of consecutive functional naming elements. For instance, the DS200SHCAG1BAA functional product number is started off by a dual-functional naming element in the DS200 series tag describing indirectly this DS200SHCAG1BAA device's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other relevant hardware details revealed in this Mark V Series PCB's full product number includes its:
- SHCA functional product abbreviation
- Normal PCB coating style
- Group one Mark V Series product grouping
- Three-fold revision table
