A Shunt Connector card; the DS200SHCAG1B printed circuit board was developed by manufacturer GE Industrial Systems as a member of the EX2000 series of excitation control systems.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200SHCAG1B to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200SHCAG1B
  • SKU: DS200SHCAG1BGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200SHCAG1B Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS200SHCAG1B
Functional Acronym SHCA
Functional Description Shunt Connector Card
PCB Coating Normal Coating
Functional Revision 1 B

Product Description

The DS200SHCAG1B is a printed circuit board that is designed as a Shunt Connector module for the Speedtronic Mark V series of turbine control units. The DS200 set of circuit boards is available in our inventory at AX Control Inc. We provide an exceptional amount of industrial automation hardware. Our models available are able to be purchased as either used, completely re-optimized hardware, and as brand new surplus products. The Speedtronic Mark V series is an advanced line of turbine control and management modules, although it is considered a legacy series, having been discontinued by the original manufacturer. These units are outfitted to be installed into a number of different types of turbines, including industrial power generator turbines, as well as gas and steam powered turbines.

Hardware Tips and Specifications

The DS200SHCAG1B Shunt Connector Card physically is designed like any other similar printed circuit board in the Mark V Series. The exposed frame is a light green hue, and is outfitted with the necessary terminals and hardware attachments to be able to mount it into a Speedtronic Mark V control drive unit. While the DS200SHCAG1B may appear similar or exactly the same to a range of other Speedtronic Mark V parts, a number of unique components are discoverable through use of a simple visual inspection. Two factory-made holes are present on either end of the Shunt Connector Card, labeled clearly as "MOTOR" and "BRIDGE". Various other labellings are present on this PCB's base board as well; including SHPL, VFBK, 6BA00, CCi 1-0, 9924, and E3. Most of these labels seem to correspond with various component part available on the base board of the DS200SHCAG1B, which is also printed with its individualized product number. This is a very small model of component circuit board, and is slender, measuring about eight inches across by two inches tall. Before making a purchase decision, please remember the functional revision of "B" present on this model; as it may change the original factory-specified dimensions or performance mechanics.

All of these aforementioned components affixed to the base circuit board of this Shunt Connector Card are protected by a layer of circuit board protective coating. This protective coating, designated as a normal-style protective coating for the DS200SHCAG1B, is a thick layer of chemically-applied voltage-protective coating. While significantly thicker and somewhat more difficult to permeate than conformal-style PCB coating; normal coating is not considered completely exhaustive over every surface of every PCB component part, and only provides a significant base protection. This DS200SHCAG1B Connector Card's PCB coating style was revealed through a diligent individualized part number breakdown; as outlined in the manuals tab above. Other information revealable through a similar part number inspection for this model includes a specific functional revision type, original manufacturer location, industry-known functional acronym, and more.

AX Control Inc. is able to provide the DS200SHCAG1B Shunt Connector Card with our extensive, unmatched protective warranty. The coverage ranges for up to three years, considering this product's status as a General Electric Printed Circuit Board, and automatically goes into effect after purchasing it.

We offer a method of lowering our price quote as well. Utilizing our exchange credit program, for any non-functional pieces of industrial hardware you have, we will dispose of it in exchange for a lowered price quote.

Frequently Asked Questions about DS200SHCAG1B

What is the purpose of a shunt within the greater DS200SHCAG1B printed circuit board assembly?

Shunts are important pieces of circuitry as they are typically used to divert overpowered voltage currents away from damaging important component boards.

What type of revision does the DS200SHCAG1B have?

The DS200SHCAG1B features a singular functional revision rated at a "B" grade. This is discoverable through a careful analysis of the DS200SHCAG1B product part number, as described above in the "manuals" tab.

Where was this DS200SHCAG1B Component PCB manufactured?

As designated through the inclusion of the "DS200" portion present in this PCB's individualized product number, the DS200SHCAG1B was manufactured in the United States; more specifically in General Electrics' Salem, Virginia plant.

Reviews For DS200SHCAG1B

Internal Review
(5.0)

A solid Mark V legacy series offering that sports a B-rated functional revision; the DS200SHCAG1B Shunt Connector module is a crucial element in the greater Mark V drive assembly, providing important voltage channeling and protections. This part may be referred to as its functional industry acronym "SHCA" more often than not in relevant industry circles, and is available for both repair and replacement right here at AX Control. The standard lead repair time for this modle PCB stands at one to two weeks, although rush shipping is available for an additional cost. - AX Control Lead Technician.
