The DS200SDCCG5A Drive Control Board was manufactured by General Electric for the Mark V Speedtronic Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200SDCCG5AHD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200SDCCG5AHD
  • SKU: DS200SDCCG5AHDGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200SDCCG5AHD Technical Specifications

OEM General Electric
Series Mark V Speedtronic
Functional Part Number DS200SDCCG5AHD
Functional Abbreviation SDCC
Revision Quantity 3 Revisions
Assembly Type Normal Assembly
Mark V Series Grouping Group 5

About the DS200SDCCG5AHD

The DS200SDCCG5AHD is a drive control card for certain Mark V Speedtronic applications. G2 versions of this board were never manufactured, but there are G1, G3, G4, and G5 versions. Please be sure to order the correct board for your application. This board was replaced by the DS215SDCC circuit board. It is important to note these boards are not backward compatible due to added components on the DS215 board. The Mark V Series that this DS200SDCCG5AHD printed circuit board was originally manufactured for is one of the final General Electric Mark product series to make use of their patented Speedtronic control system technology, although it is worth mentioning that this DS200SDCCG5AHD circuit board's greater Mark V Series is considered a now-obsolete legacy product series due to its manufacturing discontinuation in the years following its initial release.

Hardware Tips and Specifications

The DS200SDCCG5AHD contains the main control circuitry and software needed for a drive or an exciter. The board includes interface circuitry to allow it to connect to and communicate with other boards, and to process signals from these boards. The board includes a number of advanced Xilinx chip components along with other integrated circuits. This includes the drive control processor and a motor control processor as well as a co-motor processor. Other board components include multiple resistor network arrays,  jumper switches, DIP switches, a reset button, and a number of capacitors, resistors, and diodes. The board also has vertical pin connectors along with several sets of standoffs that allow daughterboards to be mounted to the SDCC to increase and expand its capabilities. The DS200SDCCG5AHD is marked with the GE logo and with the board id number. It has been drilled at each corner to allow for mounting.  For additional information regarding the proper handling and installation of this component, please refer to original documentation from the OEM like manuals and user guides.

The above information represents about the extent of original DS200SDCCG5AHD board hardware information revealable upon an analysis of its originally-printed instructional manual materials. The noted lack in this DS200SDCCG5AHD product's online instructional manual materials is due to this DS200SDCCG5AHD product's placement in a now-obsolete General Electric legacy series, as described above. With this being true, this DS200SDCCG5AHD product's DS200SDCCG5AHD functional product number gains a new importance, as several of this DS200SDCCG5AHD PCB's important hardware details and specifications are embedded in its different functional chunks. The DS200SDCCG5AHD functional product number begins with the DS200 series tag delegating this DS200SDCCG5AHD product's normal Mark V Series assembly as well as its domestic location of original manufacture. This is followed in the DS200SDCCG5AHD functional product number by an instance of the SDCC functional abbreviation, which itself is followed in the product number by another dual-functional naming component in the G5 series grouping tag. The G5 series grouping tag here represents this Mark V Series product's normal PCB coating style as well as its attribution to the fifth grouping of Mark V Series products. The final three trailing alphanumeric digits in the DS200SDCCG5AHD functional product number are telling of this DS200SDCCG5AHD PCB's three significant product revisions, including two functional product revisions and an artwork configuration revision.

Frequently Asked Questions about DS200SDCCG5AHD

Why are this DS200SDCCG5AHD Drive Control Board's three significant revisions not considered backwards-compatible?

This DS200SDCCG5AHD PCB's three significant product revisions are not backwards-compatible as two different styles of product revision have been introduced to this DS200SDCCG5AHD PCB's assembly.

Is this DS200SDCCG5AHD printed circuit board product available for repair here?

Yes. AX Control is happy to offering this DS200SDCCG5AHD PCB for both repair and replacement, with a standard one to two week lead time on most repairs.

Reviews For DS200SDCCG5AHD

Internal Review
(5.0)

While this DS200SDCCG5AHD printed circuit board product offering may not exist as the most well-documented General Electric product, primarily due to its classification within the now-obsolete Mark V legacy control system series, it is nonetheless identifiable as a well-supported product offering that makes use of the heralded Speedtronic Control System technology. This DS200SDCCG5AHD Drive Control Board's assembly additionally incorporates the seldom-seen H-rated secondary functional product revision as well. - AX Control Lead Technician
