The DS200LRPAG2AGF model is part of the Mark V DS200 series produced by General Electric; this model is considered a line relay protection option. There is only one female connector available on this model.



Sell Surplus: Have a DS200LRPAG2AGF to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200LRPAG2AGF
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200LRPAG2AGF Technical Specifications

Part Number DS200LRPAG2AGF
Series Mark V DS200
Manufacturer GE General Electric
Functional Acronym/Abbreviation LRPA
Product Type Line Relay Protection Model
Weight Approximately 2 pounds

Product Description

The DS200LRPAG2AGF is a GE board component manufactured as a part of the Speedtronic Mark V gas/steam turbine management system.  This is one of the later Speedtronic systems and was only the second to offer triple modular redundant control.  The Speedtronic line began in the late 1960s with the release of the Mark I and continued development through the turn of the century with the Mark VIe.   Mark V Speedtronic components and other Speedtronic components can be purchased from AX Control as fully tested and reconditioned units.

The DS200LRPAG2AGF is designed to function as a Line Protection card.   This is a small rectangular board with drill holes at each corner and along each edge. The board is heavily populated by components like transistors mounted in heat sinks, high-voltage electrolytic capacitors, relays, transformer components, jumper switches, potentiometers, and resistor network arrays.  The board also has several connectors in the form of four terminal strips located side-by-side on one long edge, a vertical female connector, and stab-on connectors.   The board also has a switch component, LED indicators, and various ICs along with diodes, resistors, and capacitors.

The DS200LRPAG2AGF model is now considered obsolete due to no longer being produced by General Electric, but it can still be found on the market in new and used surplus. AX Control does its very best to keep this model on its shelves to make sure that you have access to purchase another one if damage occurs to yours.

Frequently Asked Questions about DS200LRPAG2AGF

Is there a functional difference between the DS200LRPAG2AGF and LRPAG1 models?

It is unknown whether or not there are any functional differences between the two groups of LRPA models due to a lack of documentation. When visually inspecting the board, there are no physical differences between the two models; they are both equipped with a variety of LEDs, electrolytic capacitors, and even more. Both boards also have terminal strips located along one edge of the board.

What are the LEDs on the DS200LRPAG2AGF model used for?

The LEDs on the DS200LRPAG2AGF model or any of the Mark V models are typically used for status and activity indication. One of the possible uses of the LEDs is to indicate whether or not power is connected to the model, but it is unsure what the LEDs do as there is no documentation on how the LEDs function.

How can I find the manual for this model?

It is difficult to find the manual for this model since it is no longer in production by General Electric. The best way to search for the manual is to describe the board and give the part number and manufacturer.

Reviews For DS200LRPAG2AGF

Internal Review

When using the DS200LRPAG2AGF model, it is recommended that extreme care be taken to prevent damage; if the model obtains damage, it is possible that it could cause errors to the drive as well as attached prime movers. Before using the model, visually inspect the unit to make sure all connectors are in place and that there is no debris in or around the terminal strips. - AX Control Tech
