About the DS200LRPAG1PR1A
The DS200LRPAG1PR1A functions as part of the Mark V turbine control system from General Electric. Commonly this board is also used within EX2000 excitation systems. The Mark V is one of GE’s Speedtronic turbine control systems; these systems have been used for decades to offer reliable control options for the management of gas and steam industrial turbine systems.
This DS200LRPAG1PR1A PCB's greater Mark V Series still attracts quite a good bit of solid interest on the general automated industrial marketplace, both for its specific turbine-oriented applications and for its status as one of the final-developed GE product series to make use of the aforementioned patented Speedtronic technology.
Hardware Tips and Specifications
The DS200LRPAG1PR1A board functions as a line module protection card. It has four terminal blocks located along one edge. Each of these terminal blocks has individually labeled connections. Additionally, the board includes other connection options like vertical stab-on connectors and female pin connectors. There are also other mounted components on the board’s surface like:
- jumper switches
- transformers
- potentiometers
- several heat sinks
- resistor network arrays
Most of these previously-listed hardware components inn this DS200LRPAG1PR1A PCB's normal Mark V Series assembly are actually Mark V Series-standardized hardware components intended for voltage suppression and regulation processes specifically. Within each heat sink, there is a mounted transistor. The board also includes LED indicators, several integrated circuits for a number of board tasks, mounting eyelets, riyals, and a switch component. Several factory-drilled installation holes have been made in this DS200LRPAG1PR1A PCB's base circuit board to aid in normative and safe installation practices.
This DS200LRPAG1PR1A device is not the originally-designed device of its specific Mark V Series functionality; that would be the DS200LRPAG1 parent PCB missing this DS200LRPAG1PR1A product's three-fold revision history.
This DS200LRPAG1PR1A device's originally-printed instructional manuals and datasheets are largely unavailable online for the purposes of this DS200LRPAG1PR1A personalized product page. With this being true, the DS200LRPAG1PR1A functional product number itself is accepted as a solid supplementary source of DS200LRPAG1PR1A Board hardware information; coding for specific details in a series of consecutive functional naming elements.
For instance, the DS200LRPAG1PR1A functional product number is started with an inclusion of the dual-functional DS200 series tag delegating this DS200LRPAG1PR1A PCB's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other relevant hardware details revealed through this DS200LRPAG1PR1A Board's functional product number includes its:
- LRPA functional product abbreviation
- Group one Mark V Series product grouping
- Normal PCB coating style
- Three-fold revision table
