About the DS200LRPAG1A
The DS200LRPAG1A is a General Electric circuit board component fabricated as a modular part of the Speedtronic Mark V system. This system was one of the later gas and steam turbine control systems released by GE under the Speedtronic name, which began in the 1960s with the Mark I. The MKV can be used as either a Simplex or as a TMR (triple modular redundant) system of control. Both setups offer high reliability, the Simplex via software-implemented fault tolerance, and the TMR using that and its triple redundant architecture. Both setups offer a direct sensor interface, built-in diagnostics, online maintenance, and have a common hardware platform for steam and gas applications, as indicated in the Mark V Serie's full extended series name as the Mark V Turbine Control System Series. This DS200LRPAG1A Line Protection Board does not exist as the originally-desiged product of its specific Mark V Series functionality; that would be the DS200LRPAG1 parent Line Protection Board not making use of this DS200LRPAG1A PCB's distinctive A-rated functional product revision.
Hardware Tips and Specifications
The DS200LRPAG1A functions as a Line Protection board. As with any Mark V Series product offering made available to our extensive new and reconditioned inventory of printed circuit board products here, this DS200LRPAG1A PCB's intended series functionality is introduced with its normal Mark V Series assembly's acceptance of a specific series of functionality-inducing hardware components and component specifications. For starters, any voltage suppression or regulation taking place in the normal assembly of this DS200LRPAG1A PCB would be handled by its Mark V Series-standardized selection of voltage limitation-minded components such as resistors and specialized capacitors. This is a rectangular board with drill holes in each board corner as well as others along each edge. These allow for mounting options and can be populated by standoffs or by screws. The board has a wide variety of components that include high-voltage electrolytic capacitors, transistors mounted to heat sinks, jumper switches, relays, potentiometers, integrated circuits, diodes, and resistors. The board also has a vertical female cable connector, stab-on connectors, two terminal strips, LED indicators, a reset switch, and a transformer component. The two large ports at the bottom of this DS200LRPAG1A PCV weigh it down significantly and extended the total height of the product as well.
For step-by-step instructions regarding proper installation or handling of the DS200LRPAG1A, or for a more detailed description of the board components and their use, please review user guides, manuals, or other technical support products originally provided by General Electric. Originally, GE provided all tech support for the Mark V series. Given this DS200LRPAG1A Line Protection Board's initial classification in a now-obsolete Mark V Legacy product series, it should come as no real surprise to find out that this DS200LRPAG1A product is not surrounded by any great plethora of originally-printed instructional manual materials online. With this being the case, the DS200LRPAG1A functional product number can be considered a primary source of DS200LRPAG1A Board information; coding for various DS200LRPAG1A Board hardware components in a series of functional naming segments. For instance, the DS200LRPAG1A functional product number is started off by the dual-functional DS200 series tag delegating this DS200LRPAG1A PCB's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other relevant hardware details revealed by way of this DS200LRPAG1A PCB's functional product number include its:
- LRPA functional product abbreviation
- Group one Mark V Series product grouping
- Normal PCB coating style
- A-rated primary functional product revision
