DS200IQXSG1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.94 (17)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.94 (17)
  • Click a star to rate this product
The DS200IQXSG1A Inverter Snubber Board was manufactured for General Electric's Mark V series of turbine control systems.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DS200IQXSG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200IQXSG1A
  • SKU: DS200IQXSG1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200IQXSG1A Technical Specifications

Original Manufacturer GE General Electric
Product Series Mark V
Functional Part Number DS200IQXSG1A
Functional Product Description Inverter Snubber Card
Functional Acronym IQXS
PCB Coating Style Normal Coating
Functional Revision 1 A

About the DS200IQXSG1A

This DS200IQXSG1A printed circuit board was originally manufactured, as described above, for placement in General Electric's Mark V Turbine Control System Series. The Mark V Series that this DS200IQXSG1A product offering belongs to, as you can probably tell by its name, has specific applications in the management or control systems of popular wind, steam, and gas turbine automated drive assemblies, and is considered a General Electric legacy series given its eventual discontinuance of manufacture in the years following its initial release. While this DS200IQXSG1A product offering's greater Mark V Turbine Control System Series is considered a General Electric legacy series, it is also one of the latest-developed General Electric product series to make use of the company's patented Speedtronic control system technology. This DS200IQXSG1A printed circuit board is better-definable as an Inverter Snubber Board; its official functional product description as stated in Mark V Series instructional manual materials. While this DS200IQXSG1A PCB is definable as an Inverter Snubber Board, the originally-produced product of this functionality to exist in the Mark V Series is the DS200IQXSG1A Inverter Snubber Board missing this DS200IQXSG1A PCB's A-rated functional product revision.

Hardware Tips and Specifications

As this DS200IQXSG1A printed circuit board retains a functional status as an Inverter Snubber Board within its greater Mark V Turbine Control System Series, this DS200IQXSG1A PCB adopts a necessary series of functionality-introducing hardware components and component specifications. The GE Inverter Snubber Board DS200IQXSG1A features 8 terminal connectors. The terminals are labeled E1 through E8. The GE Inverter Snubber Board DS200IQXSG1A also contains 1 8-pin connector and 1 film capacitor mounted on the board. The board is 6.25 by 5 inches and it contains 1 screw hole in each corner. The holes are designed to enable you to attach the board in the board rack in the interior of the drive, and each drilled screw-hole is ringed with an insulated material. The DS200IQXSG1A functional product number details many more of this DS200IQXSG1A Inverter Snubber Board's crucial hardware specifications and classifications, beginning with its dual-naming DS200 series tag at the very beginning. The DS200 series tag that starts off the DS200IQXSG1A functional product number delegates this DS200IQXSG1A product's normal Mark V Series assembly version as well as its domestic location of original manufacture. Some of the other DS200IQXSG1A Board-specific hardware details revealed through its DS200IQXSG1A functional product number include this DS200IQXSG1A Board's:

  • IQXS functional product acronym
  • Normal PCB coating style
  • Group one Mark V Series product grouping
  • A-rated functional product revision

Before you remove the old DS200IQXSG1A board to attempt a replacement, notice where it is located in the rack and plan on using the same location to install the replacement. The defective board might have multiple signal wires connected to the wire terminals and when you install the replacement you must install the same wires in the same terminals. The wires carry signals that are transmitted from the board to other components in the drive. Other signal wires receive signals that the GE Inverter Snubber Board DS200IQXSG1A processes before transmitting to other connectors as instructions.The signal wire terminals have unique IDs that are useful for ensuring that the signal wires are reattached to the right terminals on the replacement board. Before you disconnect the signal wires draw a diagram that shows how the wires are attached to the terminals and identify the terminals by the ID. When you reconnect the wires refer to the diagram to know exactly where each wire attaches. When you connect the drive to power and restart it, you can eliminate the chance of wrong wire connections.

Frequently Asked Questions about DS200IQXSG1A

How big is DS200IQXSG1A?
DS200IQXSG1A is about 4 by 4 inches in dimension.
How many pins is the terminal strip on DS200IQXSG1A?
DS200IQXSG1A has an 8-pin terminal strip, identified by the PL nomenclature on DS200IQXSG1A. The pins on DS200IQXSG1A are separated, however, with one to the far left of DS200IQXSG1A's strip, 5 in the middle of DS200IQXSG1A's strip, and two on the right side of DS200IQXSG1A's strip.
