DS200IMCPG1CEB

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.93 (15)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.93 (15)
  • Click a star to rate this product
The DS200IMCPG1CEB IGBT Power Supply Card was manufactured by General Electric for use in the Mark V Series of turbine control systems.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DS200IMCPG1CEB to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200IMCPG1CEB
  • SKU: DS200IMCPG1CEBGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200IMCPG1CEB Technical Specifications

Manufacturer General Electric
Series Mark V
Part Number DS200IMCPG1CEB
Functional Acronym IMCP
Functional Description IGBT Power Supply Card
PCB Coating Normal Coating
Functional Revision 1 C
Functional Revision 2 E
Artwork Revision D

About the DS200IMCPG1CEB

The DS200IMCPG1CEB is designed as a circuit board from General Electric for the Mark V series. A member of the Speedtronic line, it was designed for the control of gas and wind turbines. No longer produced by the manufacturer, it features extensive built-in diagnostics and a triple-redundant design that can also be set up as Simplex should that be the need. Online maintenance is also available with this line.  While it is no longer available from the manufacturer, it can be purchased from AX Control as a refurbished and fully-tested unit. This DS200IMCPG1CEB printed circuit board is functionally-describable as a IGBT Power Supply Card, although the originally-developed product of this functionality developed for the Mark V Series is the DS200IMCPG1 parent Power Supply Card missing all three of this DS200IMCPG1CEB product's three product revisions.

Hardware Tips and Specifications

As with any Mark V Turbine Control System Series product offering, this DS200IMCPG1CEB PCB comes with its own series of functionality-introducing hardware components and component specifications. For starters, the DS200IMCPG1CEB has at least twenty-six integrated circuits and fourteen resistor arrays. The board features several different kinds of capacitors, including a ceramic disc capacitor and electrolytic capacitors, eight transistors, a varistor, and multiple heat sinks. There are two male vertical connectors, a multitude of vertical stab-on connectors, as well as a couple of LEDs. Any LED present in this DS200IMCPG1CEB printed circuit board's assembly has been included for diagnostic fault condition purposes. In addition to that, the DS200IMCPG1CEB board also has several fuses scattered across it. The board uses both CCR and metal film resistors, as well as a potentiometer. The components on the DS200IMCPG1CEB board are all marked with a reference designator and/or their original identification number assigned by the manufacturer for ease of identifying each individual component.

Given the fact that this DS200IMCPG1CEB printed circuit board is not well-documented in available General Electric instructional manual materials, other sources of original DS200IMCPG1CEB hardware component and component specification information must be accessed. The DS200IMCPG1CEB printed circuit board benefits from its General Electric manufacture as it possesses a General Electric functional product number. The DS200IMCPG1CEB functional product number begins with the DS200 series tag detailing this DS200IMCPG1CEB printed circuit board's normal style of Mark V Series assembly and its domestic original manufacture location. This initial DS200 series tag is followed by the IMCP functional product abbreviation, which was created to exist as a functional promotional and conversational shorthand alternative to the DS200IMCPG1CEB functional product number. The IMCP functional product acronym was followed in the DS200IMCPG1CEB part number by the G1 series grouping tag, another dual-functional DS200IMCPG1CEB number naming component. The DS200IMCPG1CEB number's G1 series grouping tag details this Mark V Turbine Control System Series product's normal style of PCB protective coating as well as its group one Mark V Series product grouping. The final three alphanumeric digits in the DS200IMCPG1CEB functional product number are reminiscent of this DS200IMCPG1CEB device's full three-fold revision history. Support in the form of technical sheets, manuals, and usage guides can assist in the proper installation, usage, and general safety may not be readily available. If you cannot or no longer are able to find access to these things, please ask us when you order for a copy.
