The General Electric DS200GSIAG1C Common Bus Regenerative Card was manufactured for use in the Mark V Series of turbine control systems.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200GSIAG1C to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200GSIAG1C
  • SKU: DS200GSIAG1CGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200GSIAG1C Technical Specifications

Original Manufacturer GE General Electric
Product Series Mark V
Functional Part Number DS200GSIAG1C
Functional Description Common DC Bus Regenerative Card
Functional Acronym GSIA
PCB Coating Style Normal Coating
1st Functional Revision C

About the DS200GSIAG1C

This DS200GSIAG1C Common Bus Regenerative Board was originally manufactured for placement in General Electric's Mark V Turbine Control System Series, as mentioned above. As you were probably able to ascertain from its full name, the Mark V Turbine Control System Series has specific intended applications in the management and control systems of wind, steam, and gas turbine automated drive assemblies. The Mark V Series is additionally considered to exist as a General Electric legacy series, as it has been discontinued for manufacture in the years following its initial release. This DS200GSIAG1C Common Bus Regenerative Board's Mark V Series, while considered a General Electric Legacy Series, is also classifiable as one of the final General Electric product lines to incorporate the patented Speedtronic control system technology into its products. This DS200GSIAG1C Common Bus Regenerative Board is not the originally-designed product of its functionality to act as a member of the Mark V Turbine Control System Series; that would be the DS200GSIAG1 parent printed circuit board missing this DS200GSIAG1C product offering's C-rated functional product revision.

Hardware Tips and Specifications

This DS200GSIAG1C Common Bus Regenerative Board makes use of its own specific set of hardware component inclusions and specifications to achieve its true intended functional status within the greater Mark V Series automated drive assembly. The GE Common DC Bus Regenerative Board DS200GSIAG1C contains three 40-pin connectors, two 16-pin connectors, and 6 jumpers. The board also has 1 8-pin connector, and multiple test points.  The GE Common DC Bus Regenerative Board DS200GSIAG1C might be connected to multiple cables in the drive and so if you need to replace the board you might want to examine the board and note where the cable are attached before you unplug the cables. As recommended by GE, attach a note describing where each cable is connected on the board before you disconnect them. All the connectors have a letter and number code associated with them. Use the letter and number code to know where to connect the cables on the replacement DS200GSIAG1C board. The replacement DS200GSIAG1C board might be a later version of the same GSIA model board and so will have all the improvements available at that time engineered into the version. While the location of the components might be in different locations on the DS200GSIAG1C board in a revised version, it will function the same and will be compatible with all other boards connected to it. Use care when you disconnect or reconnect the cables in the assembly of this DS200GSIAG1C PCB and avoid damaging the other components on the board or bend connector pins. When you route the cables do not block the free flow of air that cools the boards.

The above paragraph represents the bulk majority of original DS200GSIAG1C Common Bus Regenerative Board hardware specification information retrievable from any of its original pertinent instructional manual materials, given this DS200GSIAG1C product's relatively low general availability and its presence in a General Electric legacy series. With this being said, the DS200GSIAG1C functional product number itself is a good source of original hardware information for this DS200GSIAG1C PCB, beginning the the DS200 series tag that has dual naming responsibilities for this DS200GSIAG1C product offering. The DS200 series tag in the DS200GSIAG1C functional number reveals its DS200GSIAG1C PCB to be a normal assembly-model of Mark V Series printed circuit board manufactured domestically by G.E. This series tag is followed in the DS200GSIAG1C functional part number by the GSIA functional product abbreviation, which is followed by another dual-functional DS200GSIAG1C naming component in the G1 series grouping tag. The G1 tag present here details this Mark V Series printed circuit board as a PCB with a normal Mark V Series PCB coating style the belongs to the first grouping of Mark V Series products. The final C digit at the very end of the functional DS200GSIAG1C product number is telling of this DS200GSIAG1C Common Bus Regenerative Board's C-rated functional product revision.

Frequently Asked Questions about DS200GSIAG1C

Why is this DS200GSIAG1C PCB's C-rated functional revision classified as a functional product revision?

This DS200GSIAG1C product offering's singular C-rated revision is a functional product revision as it makes notable improvements to the general functionality and performance specifications of this DS200GSIAG1C board without making any sacrifices for aesthetic or durability purposes.

Does this DS200GSIAG1C Common Bus Regenerative Holes offer any factory-drilled holes for installation?

Yes. This DS200GSIAG1C printed circuit board's assembly is marked by several factory-drilled installation holes; eacch of which ringed with an insulatory material in observance of potentially-present damaging surface voltages.

Reviews For DS200GSIAG1C

Internal Review
(5.0)

This DS200GSIAG1C Common Bus Regenerative Card or Common Bus Regenerative Board is a well-supported member product of the greater Mark V Turbine Control System Series in which it was created. This DS200GSIAG1C product's crucial functional Mark V Series role is supported by various series-standardized hardware components, although it differs through its insertion of a relatively-uncommon C-rated primary functional revision. - AX Control Lead Technician
