The DS200GGXCG1A AC2000 Regen Distribution Board was manufactured by General Electric for use in their Mark V Series of turbine control systems.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200GGXCG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200GGXCG1A
  • SKU: DS200GGXCG1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200GGXCG1A Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS200GGXCG1A
Functional Description AC2000 Regen Distribution Board
Functional Acronym GGXC
PCB Coating Normal Coating
Functional Revision 1 A

About the DS200GGXCG1A

The DS200GGXCG1A is a Mark V board component manufactured by GE. This board is designed to fit within the later MKV Speedtronic systems distributed by General Electric for the management of gas and steam turbine systems. The MKV offers TMR architecture but can also be set up in Simplex form for less complicated systems. Software-implemented fault tolerance built into the design maintains the MKV’s high level of reliability even without the R/S/T triple redundant backups built into a TMR design. The DS200GGXCG1A is available from AX Control as a rebuilt, fully tested unit. It may also be available in our inventory as new never-used liquidated stock.  Ask our team to quote both options.  It is important to note DS200 boards have no firmware or hardware updates; if these are required, please review our online inventory of DS215 boards.

Hardware Tips and Specifications

The DS200GGXCG1A is a small board designed with multiple board connectors, including seven header connectors, nine stab-on connectors for wire jumpers, a vertical pin cable connector, and four fiber-optic signal interface ports.  It also has three transformer components, a heat sink, integrated circuits,  three transistors, twelve jumper switches to allow customization of the board, three high-voltage electrolytic surface mounted capacitors, along with diodes, capacitors, and resistors.  Important board usage information is printed in two charts on the surface of the board.  Factory made mounting holes are drilled in each corner, and the circuit board is marked with codes like 6BA04. For more information refer to GE data sheets, manuals, or user guides. Generally, this DS200GGXCG1A product offering can be described as a well-supported and well voltage-protected Mark V Series printed circuit board product offering, and should be treated as a static-sensitive printed circuit board given its high amount of voltage suppression-geared hardware components. In-stock products ordered before 3 pm typically ship that same day.

This DS200GGXCG1A printed circuit board, as mentioned above, belongs to a now-obsolete General Electric legacy series. With this in mind, this DS200GGXCG1A product offering's greater Mark V Turbine Control System Series does not offer many internet-available instructional manual materials. With all of this being true, the DS200GGXCG1A functional product number takes on a new importance for this DS200GGXCG1A PCB's personalized product page, identifying many of this General Electric printed circuit board's basic hardware details and specifications. The DS200GGXCG1A functional product number begins with the DS200 series tag detailing the DS200GGXCG1A PCB's normal Mark V Series assembly version as well as its domestic location of original manufacture. This dual-functional series tag is followed in the DS200GGXCG1A alphanumeric product number by an instance of the GGXC functional product abbreviation, which itself is followed in another dual-functional naming component in the DS200GGXCG1A printed circuit board's G1 series grouping tag. The G1 series grouping tag present here asserts this DS200GGXCG1A product's status as a normally-coated Mark V Series offering with a group one Mark V Series product grouping. The final A digit in the DS200GGXCG1A functional product number is telling of this DS200GGXCG1A PCB's singular A-rated functional product revision.

Frequently Asked Questions about DS200GGXCG1A

Why is this DS200GGXCG1A AC2000 Regen Distribution Board's A-rated revision considered a functional revision?

This DS200GGXCG1A PCB's A-rated product revision is a functional revision as it alters the basic performance specifications and general functionality of the DS200GGXCG1A PCB without making any notable sacrifices for durability or aesthetic purposes.

Would this DS200GGXCG1A printed circuit board be protected by any warranty following my purchase here?

Yes. Immediately upon your original purchase from AX Control, this DS200GGXCG1A PCB and many others would be considered protected by our guaranteed three-year PCB warranty.
