GE High Voltage Gate Interface Board DS200FHVAG2ADA

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a DS200FHVAG2ADA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200FHVAG2ADA
  • SKU: DS200FHVAG2ADAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200FHVAG2ADA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
GE High Voltage Gate Interface Board DS200FHVAG2ADA

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a DS200FHVAG2ADA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200FHVAG2ADA
  • SKU: DS200FHVAG2ADAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200FHVAG2ADA Technical Specifications

Instruction Manual GEI-100224
Manufacturer GE General Electric
Part Number DS200FHVAG2ADA
Product Type High Voltage Gate Interface Board
Series Mark V

Product Description

The GE High Voltage Gate Interface Board DS200FHVAG2ADA is an interface between the SCR bridge and the LCI power converter and also provides cell monitoring functions to the LCI power converter. The DS200FHVAG2ADA boards features a fiber optic connector that requires some consideration. The connector transmits a status of the board to the receiving equipment.

There might be a cause for the connector to be without a cable installed in it for a period of time. If that is the case, simply install a plug cover over the connector to prevent dust or dirt to settle on the connector. To maintain a high-quality signal, always install a plug when you disconnect the fiber optic cable from the connector.

The DS200FHVAG2ADA board is packaged in a shipping container to protect the board from damage. Inspect the box for evidence of damage, water damage, or that the box was opened during transit. Cut through the security tape and examine the contents. Save all the manuals and other written material for future use. Notice that the board is contained in a static safe bag. The only safe way to hold the board is by the edges to protect the delicate components on the board. When you are prepared to install the board, pick it up and locate a bare metal surface near the drive. Right before you install the board touch the board to the bare metal for a few seconds. Any static on your body or the board will be drained off.

Frequently Asked Questions about DS200FHVAG2ADA

What's included in Manual GEI-100224 for DS200FHVAG2ADA?
The Manual for DS200FHVAG2ADA, Manual GEI-100224, is the GE Motors and Industrial Systems High Voltage Gate Interface Board Manual for DS200FHVAG2ADA. This instruction manual does not cover all details or variations of DS200FHVAG2ADA, nor does the manual provide every possible contigency to be met during installation, operation, and maintenance of DS200FHVAG2ADA, but the manual provides essential information on DS200FHVAG2ADA. The manual provides a functional description of DS200FHVAG2ADA, application data for DS200FHVAG2ADA, and the manual also provides information on renewal/warranty replacement terms and procedures for DS200FHVAG2ADA.
What does the gate termination circuit on DS200FHVAG2ADA do?
DS200FHVAG2ADA's gate termination circuit rectifies the output of the gate transformer, provides sufficient burden resistance to ensure good noise immunity for DS200FHVAG2ADA, and connects DS200FHVAG2ADA to the SCR gate leads.
How do I replace a DS200FHVAG2ADA board?
To replace a DS200FHVAG2ADA board, it is best to view the procedure for replacing FHVA boards in the manual for DS200FHVAG2ADA. This section in the manual provides a step-by-step proceduring for replacing a DS200FHVAG2ADA board. We can also replace your DS200FHVAG2ADA board for you, or speak to a sales representative about a repair on your DS200FHVAG2ADA board.
How many DS200FHVAG2ADA boards do I need with an SCR?
There is one DS200FHVAG2ADA or other FHVA board for each SCR. DS200FHVAG2ADA is the necessary SCR gate interface.

Repair Services For DS200FHVAG2ADA

Type Lead Time Price Action
Repair Service 1-2 weeks $1165

Our highly skilled technicians can repair your DS200FHVAG2ADA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
