About the DS200FHVAG1ADA
The DS200FHVAG1ADA special-purpose board is part of GE’s Mark V Speedtronic turbine control system series. Please note this is only one version of this board available within our on-hand stock, so be sure to order the correct version of this PCB for your particular application. This DS200FHVAG1ADA printed circuit board product offering, while the only version of its specific functional role available for purchase here, is not considered the originally-developed product of its specific Mark V Series functionality; that would be the DS200FHVAG1 parent printed circuit board missing this DS200FHVAG1ADA PCB's full three-fold revision table. Most commonly, it is safe to replace a board with an exact duplicate that matches all letters and numbers in the part ID. As you may have been able to guess based off of its full extended series name, the Mark V Series that this DS200FHVAG1ADA printed circuit board or PCB for short belongs to has specific applications in the management and control systems of popular, compatible wind, gas, or steam turbine automated drive assemblies. While this DS200FHVAG1ADA PCB's greater Mark V Series may have some newer alternative energy focuses, it still must be considered a generally-obsolete GE product series, as it exists specifically as a now-discontinued legacy product series whose production ceased in one of the many years following its initial GE release. While this DS200FHVAG1ADA PCB's greater Mark V Series is a legacy product series, it is still desirable generally, as it is one of the final-release General Electric product series to make use of the patented Speedtronic control system technology across a slew of its offerings.
Hardware Tips and Specifications
The DS200FHVAG1ADA board functions as a high voltage gate interface board. It is used as an SCR gate interface and provides cell voltage monitoring for the LCI power converter. Each SCR within the Mark V system uses one of these boards. The board uses convection cooling and does not require a fan or a power supply. Please note the DS200FHVAG1ADA has an identified potential shock and burn hazard. Be sure you understand all risks before beginning any sort of installation or maintenance procedure. The DS200FHVAG1ADA includes an SCR Cell status circuit, a gate termination circuit, and a gate pulse transformer. The gate pulse transformer uses a toroidal current transformer that has been soldered to the board. Additionally, there is a diagnostic LED that will provide a visual indication of bridge power. More information about the DS200FHVAG1ADA and its use can be found by using original manuals and other documentation provided by the OEM. GE manuals were provided with your original purchase. If you need replacements at this time, we can typically help with that. Let us know when you place your order if documentation is needed.
The above-included information is primarily reminiscent of hardware components and component specifications visible in the assembly of this DS200FHVAG1ADA printed circuit board product offering, as necessitated by this DS200FHVAG1ADA product's legacy series status and its concurrent lack of originally-printed instructional manual materials online. Given this notable lack, the DS200FHVAG1ADA functional product number itself can actually be considered a strong primary source of DS200FHVAG1ADA Board hardware component and component specification information; coding for various DS200FHVAG1ADA Board hardware details in a series of consecutive functional naming chunks. For example, the DS200FHVAG1ADA functional product number begins with the dual-functional DS200 series tag delegating this DS200FHVAG1ADA PCB's normal Mark V Series assembly as well as its domestic original manufacture location. This dual-functional series tag is followed in the DS200FHVAG1ADA functional product number by an instance of the FHVA functional product abbreviation, which was created to exist as a convenient functional shorthand alternative to the lengthy DS200FHVAG1ADA functional product number. This naming component is followed in the DS200FHVAG1ADA number by the G1 series grouping tag; another dual-functional naming component describing this DS200FHVAG1ADA PCB's normal PCB coating style and Group one Mark V Series product grouping. The final three trailing alphanumeric digits on the DS200FHVAG1ADA functional product number are callbacks to this DS200FHVAG1ADA PCB's three significant product revisions.
