About the DS200FCGDH1BAA
The DS200FCGDH1BAA circuit board functions as a gate distribution status card. This board was developed by GE (General Electric) for the company’s Speedtronic Mark V series. Like other Speedtronic systems, the Mark V is designed for the control and management of industrial gas and steam turbines. AX Control maintains on-hand stock of replacement parts for all Speedtronic systems, from the Mark I to the Mark VIe. Please let us know what we can help you with. As with any other component, all parts of the identification number are important. Make sure you are ordering the correct board for your particular application. The Mark V Series that this DS200FCGDH1BAA PCB belongs to has to be considered an obsolete legacy product series, as its manufacture was discontinued in one of the years past its initial release due to a manufacturer-identified functional obsolescence. This DS200FCGDH1BAA PCB's Mark V Series, while an obsolete legacy series, is still very much a desirable product series on the greater automated industrial marketplace, given its stated Speedtronic control system technology and its specific turbine-minded applications.
Hardware Tips and Specifications
The DS200FCGDH1BAA functions as a gate distribution board. When it has been installed into a drive system, the board offers an interface system for phase-controlled non-reversing bridge systems. A connecting DSPC board relays information to this board, which is then deciphered and fed back out of the drive’s VME backplane. The DS200FCGDH1BAA includes an attached front faceplate. This has two clip components that will hold the module in place after it has been inserted into the drive. The faceplate includes multiple LED indicators along its lower surface. The top includes openings to connector ports. The DS200FCGDH1BAA is populated with multiple integrated circuits, including a Xilinx FPGA. The rear surface of the board is taken up by two horizontal male connectors. More information about the board, how it should be installed and maintained, and how it should be handled, can be found through original documentation like GE manuals and user guides.
Given this DS200FCGDH1BAA printed circuit board product offering's initial attribution to a now-obsolete legacy product series, many of its originally-printed instructional manual materials and documentation has been lost or removed online for the research purposes of this DS200FCGDH1BAA personalized product page. With this being true, the DS200FCGDH1BAA functional product number itself can be considered a primary source of this DS200FCGDH1BAA PCB's hardware component and component information; coding for specific details in a series of consecutive functional naming segments. For example, the DS200FCGDH1BAA functional product number begins with the dual-functional DS200 series tag delegating this DS200FCGDH1BAA PCB's normal Mark V Series assembly as well as its domestic original manufacture location. This dual-functional tag is followed in the DS200FCGDH1BAA functional product number by the FCGD functional product abbreviation, an abbreviation created to exist as a convenient conversational and promotional shorthand alternative to the DS200FCGDH1 parent printed circuit board. The DS200FCGDH1BAA functional product number is continued through another dual-functional component inclusion in the H1 series grouping tag delegating this DS200FCGDH1BAA PCB's conformal PCB coating style as well as its group one Mark V Series product grouping. The final three alphanumeric digits in the DS200FCGDH1BAA functional product number are telling of this DS200FCGDH1BAA Device's possession of a full range of three total product revisions, including two functional revisions rated B and A and an artwork configuration revision rated at an A grade.
