The DS200DSFBG1ADB Driver/Shunt Feedback Board

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200DSFBG1ADB to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200DSFBG1ADB
  • SKU: GBTC-54085
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200DSFBG1ADB Technical Specifications

OEM General Electric
Series Mark V Speedtronic
Part Number DS200DSFBG1ADB
Functional Description DS200DSFBG1ADB
Functional Abbreviation DSFB
Assembly Type Normal Assembly
Mark V Series Grouping Group 1

About the DS200DSFBG1ADB

The DS200DSFBG1ADB functions as a driver and shunt feedback board, and therefore only has a few components mounted. The DS200DSFBG1ADB board itself is almost perfectly square; however, two board edges are marked for board stiffeners to be installed; these installation guidelines will help you with proper orientation. The DS200DSFBG1ADB board should not be used on locations where vibration and shock may be significant unless board stiffeners have been properly installed first, as these protect solder joints and tracesThe DS200DSFBG1ADB board is only minimally populated. Components include:

  • resistor network arrays
  • diodes
  • transformers
  • transistors
  • metal film resistors
  • stab-on connectors
  • plug connectors
  • LED indicators
  • integrated circuits
  • factory drilled holes

DS200DSFBG1ADB Device-Specific Catalog Number

Given the fact that this DS200DSFBG1ADB printed circuit board or PCB for short is not featured in detail in any online-available instructional manual materials, it should come as no surprise that the DS200DSFBG1ADB functional product number itself is a strong source of original hardware specification information for this device.

The DS200DSFBG1ADB functional product number begins with the DS200 series grouping tag detailing this DS200DSFBG1ADB product's:

  • normal assembly type
  • and domestic location of original manufacture

This DS200 series tag is followed in the DS200DSFBG1ADB functional product number by the DSFB functional abbreviation; which was created to exist as a convenient conversational and promotional shorthand for the lengthy DS200DSFBG1ADB functional product number. This DSFB abbreviation is followed in the DS200DSFBG1ADB number by the G1 series grouping tag; another dual-functional DS200DSFBG1ADB number element, this time detailing the DS200DSFBG1ADB board's:

  • normal style of printed circuit board coating
  • its group one Mark V Turbine Control System Series grouping

The final three digits in the DS200DSFBG1ADB functional product number are telling of this DS200DSFBG1ADB Driver/Shunt Feedback Board's A, D, and F-rated significant product revisions.


Frequently Asked Questions about DS200DSFBG1ADB

What types of revisions are featured in the assembly of this DS200DSFBG1ADB product?

This DS200DSFBG1ADB Driver/Shunt Feedback Board features two functional product revisions and an artwork configuration revision; rated at A, D, and B grades respectively.

Would this DS200DSFBG1ADB Driver/Shunt Feedback Board be protected by any warranty following my purchase?

Yes. Immediately upon your original purchase from AX Control, this DS200DSFBG1ADB printed circuit board would be protected by our guaranteed, three-year product warranty.

Reviews For DS200DSFBG1ADB

Internal Review
(5.0)

This three-times revised DS200DSFBG1ADB Driver/Shunt Feedback Board is a well-supported and specifically-important product offering existing within the greater Mark V Turbine Control System Series. This DSFB-abbreviated Driver/Shunt Feedback Board makes use of several of the standard voltage-limiting hardware components of the Mark V, and is stabilized through its unique inclusion of numerous Mark V Series board stiffeners. This DS200DSFBG1ADB printed circuit board is available today for repair and replacement. - AX Control Lead Technician
