About the DS200DCPAG1ABB
The DS200DCPAG1ABB board is part of the Mark V Turbine Control System Series produced by General Electric. The Mark V Series that this DS200DCPAG1ABB printed circuit board product offering belongs to has specific applications in the control and management systems of popular and compatible wind, gas, and steam turbine automated drive assemblies, and must be considered to exist as a now-obsolete legacy series given its eventual manufacturing discontinuation that took place in one of the many years following its original General Electric product series release. This DS200DCPAG1ABB PCB's Mark V Series, while now-obsolete, is still considered quite the desirable General Electric Mark product series on the industrial automated marketplace, as it exists as one of the final-developed Mark product series to incorporate the patented Speedtronic control system technology into its various offerings. While this DS200DCPAG1ABB printed circuit board is definable in its own right as a Control Processor Board, the originally-developed product of this specific Mark V Series functionality is the DS200DCPAG1 parent Control Processor Board missing this DS200DCPAG1ABB PCB's extended three-fold revision history.
Hardware Tips and Specifications
This board is described as a Control Processor Board. This DS200DCPAG1ABB board can be used in gas and/or steam turbine systems. This board has the ability to be used in several redundancy applications, it can be used in triple modular redundant (TMR), simplex, and dual redundant applications. There are several connectors on the side edge and the bottom edge of the DS200DCPAG1ABB board, these are vertical pin connectors that range from thirteen to twenty pins. There are also seventeen integrated circuits on the board and up to twenty-four resistor network arrays. There are also resistors, transistors, diodes, and capacitors on the board; all Mark V Series-standardized hardware components developed for voltage suppression and limitation specifically. Typically this DS200DCPAG1ABB PCB's resistors will be made up of metal film, with the capacitors ranging from large axial capacitors and small ceramic capacitors. These two different types of capacitors are made from electrolytic material or polyester vinyl. The DS200DCPAG1ABB board is widely available in new and used surplus on the market. For any information regarding this board can be found in General Electric publications. For specific pricing information please contact AX Control’s sales department Monday through Friday, eight a.m. to five p.m. for pricing information, as well as shipping information. General Electric boards come with a three-year warranty.
This DS200DCPAG1ABB printed circuit board's greater Mark V Series is not well-documented online for the sake of this DS200DCPAG1ABB personalized product page; most likely a result of this DS200DCPAG1ABB Device's Mark V Series' legacy product series attribution. With this in mind, the DS200DCPAG1ABB functional product number itself can be considered a strong source of DS200DCPAG1ABB Board hardware component and component specification information; coding for these details in a series of consecutive functional naming chunks. For example, the DS200DCPAG1ABB functional product number begins with a dual-functional naming chunk in the DS200 series tag describing this DS200DCPAG1ABB printed circuit board's domestic original manufacture location as well as its normal style of Mark V Series assembly. Some of the other relevant hardware details revealed through use of this DS200DCPAG1ABB PCB's DS200DCPAG1ABB functional product number include its:
- DCPA functional product abbreviation
- Normal PCB protective coating style
- Group one Mark V Series product grouping
- A-rated functional product revision
- B-rated secondary functional product revision
- B-rated artwork configuration revision
