The DS200DACAG1ACD TC/DC AC/DC Converter Board was manufactured for General Electric's Mark V Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200DACAG1ACD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200DACAG1ACD
  • SKU: DS200DACAG1ACDGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200DACAG1ACD Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS200DACAG1ACD
Functional Description TC/DC AC/DC Converter Board
Functional Acronym DACA
PCB Coating Normal Coating
Functional Revision 1 A
Functional Revision 2 C
Artwork Revision D

About the DS200DACAG1ACD

The DS200DACAG1ACD is a board component within GE’s Mark V Speedtronic system. This is a legacy part that is no longer manufactured by General Electric. However, it can be purchased from AX Control as new never-used surplus or as a reconditioned unit sourced from previously used industrial stock. The Mark V Series that this DS200DACAG1ACD product offering belongs to is one of the final General Electric product series to make use of their patented Speedtronic control system technology first introduced alongside the rollout of the Mark I in the late 1960s. This DS200DACAG1ACD printed circuit board is truly better-definable through its official functional product description as a TC/DC AC/DC Converter Board, although the originally-manufactured product of this functionality to feature within the Mark V Series is the DS200DACAG1 parent printed circuit board missing this DS200DACAG1ACD product's three-fold revision history.

Hardware Tips and Specifications

The DS200DACAG1ACD is a double-sided board with components mounted to both the top and bottom surfaces. The board is shaped along three of its four edges. The shaping includes tabs or cutouts to allow for proper installation of the board. There are also multiple factory-made drill holes made within the body of the board. These are situated as two lines of three and two lines of two, with each factory-made hole ringed with conductive material. One side of the DS200DACAG1ACD is populated with female plug connectors and wire wound resistors. This side of the board also has a single green LED indicator mounted in one corner. The board is marked with the board’s id number, with several identifying codes, and also has a barcode mounted along one edge. The GE logo is printed near the bottom edge of the board. The opposite side of the board has additional components, including a large high-voltage capacitor. For more information about the DS200DACAG1ACD board component, please consult original documents from General Electric about this board, like its individual datasheet or the Mark V series manual or user guide. Most of the Mark V components are static sensitive; therefore we will ship this board wrapped in an anti-static wrap or bag.

The paragraph above is solely reminiscent of information retrievable from a diligent visual inspection of the DS200DACAG1ACD printed circuit board itself. This is true due to the DS200DACAG1ACD PCB's status as a member of the Mark V Legacy Series ensuring that its originally-produced instructional manual materials are lost or shrouded in obscurity. With this being known, the DS200DACAG1ACD functional product number itself can be considered a strong alternative source of DS200DACAG1ACD board original hardware information, beginning with its initial DS200 series tag possessing dual DS200DACAG1ACD Board naming functionality. The DS200 series tag present at the beginning of the DS200DACAG1ACD functional product number delegates this DS200DACAG1ACD product offering's domestically-made status as well as its possession of a normal Mark V Turbine Control System Series assembly version. Some of the other details revealed in the DS200DACAG1ACD functional product number include this DS200DACAG1ACD PCB's DACA functional product abbreviation, its G1 series grouping tag, its normal PCB coating, and its possession of a full range of three significant product revisions; including two functional product revisions and an artwork configuration revision.
