The DS200DACAG1ACC AC/DC Convertor Board featured on this page was originally developed for General Electric's Mark V Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200DACAG1ACC to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200DACAG1ACC
  • SKU: DS200DACAG1ACCGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200DACAG1ACC Technical Specifications

OEM General Electric
Product Series Mark V, EX2100
Part Number DS200DACAG1ACC
Functional Acronym DACA
Assembly Type Normal Assembly
PCB Coating Style Normal Coating

About the DS200DACAG1ACC

The DS200DACAG1ACC is part of the EX2100 Excitation module from General Electric, and exists specifically as an AC/DC Converter Device. This DS200DACAG1ACC module is used for field excitation in gas generators, steam generators, and hydroelectric generators, to help control AC terminal voltage and their reactive volt-amps. The EX2100, the sub-series to which this Mark V Series product belongs to, has a modular design that makes it simple to create a specially designed system with options as needed, whether this means using simplex or redundant controls, or drawing from auxiliary, potential, or a compound power source. While this DS200DACAG1ACC AC/DC Converter board is no longer available from the OEM, it is typically available as an in-stock product here at AX Control, dependent on general market availability.

Hardware Tips and Specifications

As mentioned before, the DS200DACAG1ACC functions as an AC/DC converter board, with the unit powered by a 115 VAC source that uses the board’s components to produce a 125 VDC output. For redundancy needs, two DACA boards can be used within the greater Mark V Series turbine control system, as both boards can connect to the same Mark V Series EPDM power board. This DS200DACAG1ACC AC/DC converter Board features a lot of hardware component inclusions and specifications that are available solely based off of a visual inspection of the General Electric PCB. Some of these visible hardware choices include:

  • A singular large, blue, drum-like capacitor dwarfing the rest of this DS200DACAG1ACC board's components
  • Three metal standoffs on the bottom of the circuit board for installation use
  • Three red female ports labeled JTX1, JTX2, and JZ
  • Several factory-printed diagnostic labels, including the DS200DACAG1ACC product number itself

All of these aforementioned hardware components and component specifications should hopefully receive some form of sufficient protection from daily wear and tear from this Mark V Series product's normal style of PCB coating, which was revealed through interpretation of the G1 series tag available in the DS200DACAG1ACC functional product number. Some other hardware components and specifications unearthed with help of this functional moniker include this DS200DACAG1ACC PCB's domestic manufacture location, its normal assembly type, its DACA functional acronym, its group one Mark V Series Grouping, and its three significant product revisions.
