The DS200CTBAG1ADD Terminal Board was manufactured by General Electric for use in their Mark V Series of Control Systems.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200CTBAG1ADD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200CTBAG1ADD
  • SKU: DS200CTBAG1ADDGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200CTBAG1ADD Technical Specifications

Manufacturer General Electric
Series Mark V
Part Number DS200CTBAG1ADD
Functional Acronym CTBA
Functional Description Terminal Board
PCB Coating Normal Coating
Functional Revision 1 A
Functional Revision 2 D
Artwork Revision D

About the DS200CTBAG1ADD

The DS200CTBAG1ADD is a terminal board designed for use within the GE Mark V Speedtronic system. The Speedtronic line was created by General Electric for the control of both large and small gas and steam turbine systems. The MKV can be designed with either Simplex or TMR/triple modular redundant architecture to meet the needs of the connected turbine system. These circuit boards are no longer fabricated and distributed by GE but can be purchased through AX Control as fully tested and refurbished models. The Mark V Turbine Control System Series that this DS200CTBAG1ADD printed circuit board belongs to is considered a legacy product series, as it has been discontinued for manufacture in the many years following its initial release. This DS200CTBAG1ADD printed circuit board or PCB for short in not the original product of its specific Mark V Series intended functionality; that would be the DS200CTBAG1 Analog Termination Module missing all three of this DS200CTBAG1ADD device's three significant product revisions.

Hardware Tips and Specifications

The DS200CTBAG1ADD is a long, narrow board with only a few types of components. It is drilled at each corner and along its long edges to allow for mounting hardware and other connections. Two of these drill holes are ringed with a conductive material. Voltage regulation in the assembly of this DS200CTBAG1ADD printed circuit board product offering is handled for the most part by its standardized Mark V Series voltage-limiting hardware components; this DS200CTBAG1ADD PCB's normal Mark V Series assembly visibly sports several red-coated diodes specifically. The board is marked with identifying codes including the board ID number and the company logo. The DS200CTBAG1ADD is an Analog Termination Module.  It is typically located within the <R5> core.  The board has multiple connectors, including two COREBUS connectors (JAI and JAJ.)  The DS200CTBAG1ADD has two double-stack terminal strips located on one long board edge with multiple connectors on each terminal strip. There are five vertical pin cable connectors, two vertical pin header connectors, and a 9-pin male serial connector. Fortunately for the sake of this DS200CTBAG1ADD personalized product page, this DS200CTBAG1ADD PCB's various connectors are detailed in this DS200CTBAG1ADD device's available instructional manual materials. Each one of these connectors is accompanied by its own factory-printed nomenclature label. Some of this DS200CTBAG1ADD PCB's connectors include:

  • The 8PL STCA Board IONET Connector
  • The JAA TCCA Board 4-20 mA Output Signals Connector
  • The JAI COREBUS Connector
  • The JAJ COREBUS Connector
  • The JBB TCCA Board 4-20 mA Inputs and Shaft Voltage/Current Signals Connector
  • The JEE STCA Board COREBUS Signals Connector
  • The JPC TCPD Board 24 V dc Power Signal Connector
  • The JX TCDA Board IONET Signals Connector
  • The 6PL Connector

All of the above-listed connectors in the assembly of this DS200CTBAG1ADD Termination Module have been named through a combination of their individual factory-printed nomenclature labels, their specific Mark V Series compatible products and interfacing opportunities, and finally their specific Mark V Turbine Control System Series applications and functionalities. The 6PL Connector in this DS200CTBAG1ADD PCB's assembly has not been named as such as it exists as a vesitigial structure that typically goes unused during normative functionality of this DS200CTBAG1ADD device. Other components on the DS200CTBAG1ADD include resistor network arrays, relays, transistors, over twenty metal oxide varistors (MOVs,) over a dozen jumper switches, along with a number of capacitors and resistors. For additional information, please refer to technical support products originally provided by General Electric.

Frequently Asked Questions about DS200CTBAG1ADD

Are this DS200CTBAG1ADD PCB's two seemingly-identical D-rated product revisions considered backwards-compatible?

No. Only this DS200CTBAG1ADD PCB's first two product revisions can be considered backwards-compatible, as they exist as the same functional style of Mark V Series product revision.

Where specifically was this DS200CTBAG1ADD PCB manufactured?

This DS200CTBAG1ADD Termination Module was manufactured in General Electric's Salem, Virginia factory plant location.

Reviews For DS200CTBAG1ADD

Internal Review
(5.0)

This DS200CTBAG1ADD PCB or printed circuit board product hails from the well-respected Mark V Turbine Control System Series of well-respected retailer General Electric, as discussed above. This DS200CTBAG1ADD PCB differentiates itself from the base-revised Mark V Series Termination Module through a full revision history including two functional product revisions and an artwork configuration revision. It is interesting that this DS200CTBAG1ADD PCB is slated to be a Termination Module, given its normal Mark V Series assembly version. - AX Control Lead Technician
