This DS200CLACG1AAA Power Connect Card from General Electric was originally created for their Mark V Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200CLACG1AAA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200CLACG1AAA
  • SKU: DS200CLACG1AAAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200CLACG1AAA Technical Specifications

OEM GE Industrial Systems
Series Mark V
Product Number DS200CLACG1AAA
Product Description PC Card
Functional Abbreviation CLAC
PCB Coating Style Normal Coating
1st Functional Revision A
2nd Functional Revision A
Artwork Revision A

About the DS200CLACG1AAA

This DS2000 CLACG1AAA PC Board is a product somewhat obscure, as even its original functional description cannot be placed in original General Electric manuals concerning the Mark V Turbine Control System Series of the DS200CLACG1AAA Board specifically. With this being said, enough information about this Mark V Series Power Connect Board can be gleaned from the functional DS200CLACG1AAA product number itself and synthesized with information gathered from a visual inspection of the product to replicate an individualized product page here. The Mark V Series that this DS200CLACG1AAA printed circuit board or PCB for short belongs to is a pretty self-explanatory General Electric Mark product series, as it has specific applications in the management and control systems of GE-compatible gas and steam turbine automated drive assemblies. While this is true, the Mark V Series has to be classified as obsolete generally, as it was discontinued for manufacture due to a retailer-identified functional series obsolescence in one of the many years past its initial rollout. The Mark V Series, while generally obsolete, is still a highly-acclaimed General Electric Mark product series, as it is one of the lastly-developed Mark Series to make use of the patented Speedtronic control system technology first seen with the Mark I Series in the late 1960s.

Hardware Tips and Specifications

The GE PC Board DS200CLACG1AAA features one 2-pin connector, four test points, and four screw holes for installation. The GE PC Board DS200CLACG1AAA also features test points that can be used to test the circuits on the board. The board dimensions 2.5 inches in height and 5 inches in length. The screws are designed to align with matching holes in  the board rack in the drive. When you remove the defective drive, note where in the rack the board was situated and and also retain the four screws and washers you remove from the old board. Use two hands to remove the old board. With one hand hold the screwdriver and turn it. With the other hand hold the screws and washers to prevent them from falling into the drive.  If one or more screws and washers fall into the drive, stop the procedure and locate and retrieve the items. Any items left in the drive would be a safety hazard that might cause a shock or might damage the moving parts inside the drive. When you work on the replacement you must use a wrist strap to protect against the buildup of static. One end of the strap is wrapped around your wrist while the other end is designed with a clip that you can attach to a bare metal surface. This might be a bare metal surface on a workbench leg or support structure. Some wrist straps have a plug you attach to a matching connector on a workbench. It is crucial to follow General Electric-identified installation instructions for this Mark V Series product, as this is essential for avoiding any possible lethal surface voltages on this DS200 normal-assembly product offering.

While it is certainly important to be cognizant of applicable installation strategies for this CLAC-abbreviated Power Connect Board, the inclusion of these strategies on this page is more a reflection of the limited nature of original, product-specific Mark V Series manual materials. More information can be sourced from the DS200CLACG1AAA functional product number itself, which contains specifications such as the CLAC PC Board's normal assembly version, domestic manufacture location, normal PCB coating, and three, A-rated significant product revisions. This DS200CLACG1AAA printed circuit board product offering's voltage suppression strategy generally involves the installment of Mark V Series-standardized hardware components into its normal Mark V Series assembly. Some of these various components include different styles and renditions of Mark V Series capacitors, resistors, transistors, diodes, and even specialized integrated circuits. This DS200CLACG1AAA PCB is not the originally-devised device of its specific Mark V Series functionality; that would be the DS200CLACG1 parent PCB missing this DS200CLACG1AAA product's three-fold revision history.

Frequently Asked Questions about DS200CLACG1AAA

What types of revisions does this DS200CLACG1AAA PC Card's assembly use?

This DS200CLACG1AAA PCB uses two functional product revisions and an artwork configuration revision; all rated at grades of A.

Are this DS200CLACG1AAA PCB's three significant revisions backwards-compatible?

No. Only this DS200CLACG1AAA product's first two revisions can be considered backwards-compatible, as they exist as matching functional styles of Mark V Series revisions.

Reviews For DS200CLACG1AAA

Internal Review
(5.0)

This DS200CLACG1AAA Power Connect Card or PC Card for short is more or less another General Electric Mark V Series product offering that is not offered a complete range of information, given its absence of viable product-specific instructional manual materials available online. With this being said, this DS200CLACG1AAA printed circuit board is at least attributable as a General Electric product, which reveals some of its robust protection and performance specifications, including its usage of a full range of three product revisions. - AX Control Lead Technician
