DS200ADMAH1 Technical Specifications

Instruction Manual GEI-100218
Manufacturer GE General Electric
Part Number DS200ADMAH1
Product Type Analog to Digital Module
Series Mark V

Product Description

The General Electric DS200ADMAH1 is an analog to digital module daughterboard. Developed for the Mark V board series, this card can be used across a number of GE brand drives and exciters. This daughterboard easily installs on any drive’s DS200DSPC board. When mounted on a DSPC board, this card can buffer, filter, and convert incoming and outgoing analog and digital I/O.

Installing DS200ADMAH1 ensures that all I/O sent to and from the drive is accurate and converted properly. In total, this daughterboard provides twelve additional analog inputs to the installed drive. An additional four analog outputs are also included. When dealing with digital I/O, this card provides eight digital input output positions on the board. A programmable logic device is also available when using this drive. Logic controls are static RAM, providing an interfacing medium between the DSPC processor buses and the ADMA’s I/O features. Diagnostic indicators on the board alert users to the board’s status. Two LED indicators, along with one green IMOK LED and a red FAIL LED are all included on this card.

Provided installation parameters for both DS200ADMAH1 and the drive should be met. This will ensure that the ADMA board as well as the overall drive system operates properly. For a complete guide to wiring and installing the board to the DSPC connector is available in the device’s manual and datasheet. The manufacturer, General Electric, was the original provider of technical support for this board as well as the entire Mark V series.

AX Control’s trusted sales team is happy to assist with all of your DS200ADMAH1 needs. Please contact us by phone or email to receive current prices and availabilities on all parts and repairs.

Frequently Asked Questions about DS200ADMAH1

What does DS200ADMAH1 provide when connected to a DDTB?
DS200ADMAH1 connects to a DDTB by means of high density connectors and cables. When connected to DDTB, DS200ADMAH1's set with DDTB provides an interface to analog inputs and outputs including buffering, filtering, and conversion in both directions for the DSPC board.
What kind of memory does DS200ADMAH1 have?
DS200ADMAH1 has an add-only electronic ID memory that contains board identification and hardware revision information for DS200ADMAH1. The memory on DS200ADMAH1 is accessed through a 1-wire LAN and allows the host DSPC board to electronically identify the daughterboards that are present.
Which manual is the manual for DS200ADMAH1?
The manual for DS200ADMAH1 is Manual GEI-100218. This manual is the GE Motors and Industrial Systems Analog to Digital Module Daughterboard Manual. This manal provides a functional description of DS200ADMAH1, application data for DS200ADMAH1 including DS200ADMAH1's LEDs and connectors, and renewal/warranty replacement information for DS200ADMAH1.
How many LEDs does DS200ADMAH1 have?
DS200ADMAH1 has two LEDs on DS200ADMAH1's faceplate. The LEDs on DS200ADMAH1 indicate DS200ADMAH1's status. There is a green IMOK LED that indicates DS200ADMAH1 is functioning properly and there is a red FAIL LED that indicates when something on DS200ADMAH1 has failed.
Reviews For DS200ADMAH1
Internal Review

This analog to digital module daughterboard (ADMA) works as an auxiliary board mounting to a DS200DSPC board. It is used to connect the DSPC board to an external high voltage terminal board using high-density connectors and cables. Make sure to turn off the power to the board and verify the power is off before touching any connected circuits.--AX Control Tech Team.
