This General Electric DS200ACNAG1ABB ARCNET Board was originally manufactured for the Mark V Turbine Control System Series.



Sell Surplus: Have a DS200ACNAG1ABB to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200ACNAG1ABB
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200ACNAG1ABB Technical Specifications

OEM General Electric
Series Mark V Speedtronic
Product Number DS200ACNAG1ABB
Functional Abbreviation ACNA
Revision Quantity 3 Revisions
Assembly Type Normal Assembly
Mark V Series Grouping Group 1

Product Description

The DS200ACNAG1ABB is an ARCNET board created by General Electric for use within their Mark V turbine control systems. The Mark V was a TMR (triple modular redundant) control system created by GE for the management of industrial turbine systems, and is considered a General Electric legacy series, as its manufacturing has been discontinued by its original General Electric retailer. While this is true, the Mark V Series that this DS200ACNAG1ABB printed circuit board belongs to is one of the more recently-developed General Electric product series designed with the use of their patented Speedtronic technology. This DS200ACNAG1ABB printed circuit board is not the original Mark V Series with its specific intended functionality, however. This DS200ACNAG1ABB circuit board's normal status as the original DS200ACNAG1 ARCNET Board is destroyed through this DS200ACNAG1ABB product's inclusion of three significant product revisions.

Hardware Tips and Specifications

The DS200ACNAG1ABB is used to establish connections between the system’s regulator and ARCNET data. Given this specific functionality, numerous specialized hardware components and component specifications are included in its normal style of Mark V Series assembly. Connections made to the DS200ACNAG1ABB PCB are established using coaxial cables; the ACNA board can be used as a termination point for two total coaxial cables. The DS200ACNAG1ABB is a very small board component, with an assembly that includes two BNC connectors that extend past the top edge. Two grounding holes have been drilled through the unit, one close to each short board edge; each of these factory-drilled installation holes has been insulated in observance of potentially-present damaging surface voltages or static electricity. The center of the DS200ACNAG1ABB board has a single vertical 6-pin connector. The DS200ACNAG1ABB unit featured here is marked with the GE logo, with wiring codes, and with other identifiers including reference designations. The board’s two relays both carry relay diagrams on their upper surfaces. Finally, other DS200ACNAG1ABB ARCNET board components include transistors, integrated circuits, resistors, capacitors, and diodes, typical voltage-limiting hardware components used for the Mark V Series.

It is important to know that conventional ARCNET systems operate at a rate of 2.5 Mbps, which limits their size to under four miles. Longer distances will result in extended timeouts between nodes. Before making a purchase decision on this DS200ACNAG1ABB printed circuit board, it is important to realize that this product's originally-introduced hardware performance specifications and dimensions have likely been impacted by one of the three major product revisions in its assembly. This DS200ACNAG1ABB printed circuit board features two functional product revisions and a singular artwork configuration revision in its assembly, rated at General Electric grades of A, B, and B respectively. This DS200ACNAG1ABB PCB additionally possesses both a normal Mark V Series assembly type and a normal style of PCB coating, both details revealed through an analysis of its DS200ACNAG1ABB functional product number. AX Control does our best to keep the DS200ACNAG1ABB and other ACNA boards as ready-to-ship products as much as we can.   Talk to our staff for today’s information regarding availability and estimated shipping times.  We meet and exceed the expectations of customers around the world.  Let us know what we can help you with today.

Frequently Asked Questions about DS200ACNAG1ABB

Is this DS200ACNAG1ABB printed circuit board a fragile General Electric PCB?

Yes. The unique design and small size of this DS200ACNAG1ABB printed circuit board deems it a rather fragile Mark V Series product offering. This DS200ACNAG1ABB PCB is also considered to be static electricity-sensitive.

Would this DS200ACNAG1ABB ARCNET Board be protected by any warranty following my purchase?

Yes. Immediately upon your original purchase from AX Control, this DS200ACNAG1ABB printed circuit board would be deemed protected under our guarateed three-year circuit board warranty.

Reviews For DS200ACNAG1ABB

Internal Review

This DS200ACNAG1ABB ARCNET Board is a crucial part of its larger Mark V Turbine Control System Series and automated drive assembly, as partially evidenced by this DS200ACNAG1ABB product's possession of a full revision table including two functionality-enhancing revisions. Given this DS200ACNAG1ABB PCB or printed circuit board's attribution to the Mark V TMR Series, it is not considered compatible with Simplex systems. This DS200ACNAG1ABB ARCNET Board is available for both repair and replacement. - AX Control Lead Technician

Repair Services For DS200ACNAG1ABB

Type Lead Time Price Action
Repair Service 1-2 weeks $295

Our highly skilled technicians can repair your DS200ACNAG1ABB. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
