GENERAL ELECTRIC CURRENT ISOLATOR BOARD

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS3820CI2AG21C1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3820CI2AG21C1A
  • SKU: DS3820CI2AG21C1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

Product Description

DS3820CI2AG21C1A General Electric Current Isolator Module

The DS3820CI2AG21C1A is a General Electric module created for the Mark IV Speedtronic series.  Designed for the management of steam and gas turbine systems, the Mark IV was the first of GE’s Speedtronic systems to offer triple modular redundant fault-tolerant control that minimizes issues created by faulty hardware by creating triple backups for all critical controls and protection parameters.   Mark IV components are available from AX Control as new-used stock or as reconditioned parts that have been fully optimized by our in-house technicians.

The DS3820CI2AG21C1A is a Current Isolator Module.  It is designed to give the unit isolation between the control side and the line voltage side.  It can also switch incoming current from DC to AC.   This module has an external protective box and an internal circuit board component.  The exterior box (metal) is designed to be wall-mounted.  The unit has several flanges with screw holes or tabs to allow for mounting located on its back edge.  The front panel is hinged on its left edge.  The front panel opens to reveal the inner workings of the unit.  This panel is marked with several warnings, including a high-voltage warning.  Please be sure to read and follow all handling and safety procedures from the manufacturer before unboxing your part.

The interior DS3800NCIB board within the DS3820CI2AG21C1A component is screw-mounted to the back panel of the external box.  This circuit board is heavily covered with components including multiple connectors like a three-position terminal strip, a ribbon connector, two male vertical pin connectors, a stab-on ground connector, and a quick-connect connector for the addition of a component like a resistor or a diode.   Other board components include an isolation amplifier (S1270,)  integrated circuits, potentiometers, transistors, resistors, capacitors, and diodes.  Most components are marked with a reference designator to allow for easy identification.


Repair Services For DS3820CI2AG21C1A

Type Lead Time Price Action
Repair Service 1-2 weeks $305

Our highly skilled technicians can repair your DS3820CI2AG21C1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
